Genuine leather laser cutting machine

Brand Name	GoldenLaser		Place of Origin	China
Model Number	CJG-160250

China listed manufacturer of laser equipment.
CJG-160250 Genuine Leather Laser Cutting Machine

Product Feature
This model perfectly combines high speed galvanometer hollowing and X-Y axis large-scale laser cutting (two laser heads) together, making  continuos working with harmony, saving energy cost at the most. Meanwhile it can be also equipped with feeding system, which ensure laser engraving, laser cutting, hollowing, line cutting as whole integrative process. It enjoys high speed cutting, and improved working efficiency and quality. It's a laser cutting machine with the most automated  operation and the strongest application at present.

Application Field
Suitable for shoes, fur coat, leather fabric engraving, punching, cutting, scribing

Technical Parameter
Laser type     CO2 RF laser tube and hermetic or detached CO2 laser tube
Laser power     70W(Hollowing and cutting) 75W x 2(cutting)
Cutting area     1600mm x 2500mm Auto rolling vacuum absorb convey working table
Cutting(no-load)speed     0-48000mm/min
Stiletto(no-load)speed     0-180000mm/min
Engraving(no-load)speed     0-600000mm/min
Precision of stiletto repeating location     <0.01mm
Repeating location     <0.10mm
Moving system     Servo system, 5 inch offline display, advanced CNC control system
Cooling system     Professional constant temperature water chiller for laser cutting machine
Laser power adjustment     Following laser power adjustment
Power supply     AC220V5% / 50HZ
Format support     AI, BMP, PLT, DXF, DST etc
Standard collocation     Up exhaust filtration system, assisted air-compressor
Select collocation     Outside exhaust fans, auto-feeder system, cutting system with multi-head, assisted cutting head,loading and unloading system
*Working area and laser power can be customized according to requirement.*
