Laminating and Coating Machine

Design Principles of YM-MYM CA-1650A

The frame construction is precision-engineered that enables to meet the high requirement on foil used as holographic coated and so on.

With Yiming Paten heating system, you can reduce energy by 50% compared with normal coating machine. We guarantee a high degree of accuracy for the finishing process with online measurement. This can be ensured at the time of purchase.

Specification

1.        Working width:1650mm

2.        Coating material: PET 12~60mic, OPP/BOPP: 15~60mic

3.        Machine speed: 220m/min, coating speed: 200m/min

4.        Re-winder/Un-winder OD: 800mm

5.        Re-winder/Un-winder air shaft roller: 6

6.        Web guide system: Base style EPC

7.        Main heating tunnel: 15000mm, six zone, Inside steel

8.        Re-winder: stick roller

9.        In/out-feed Nip roller : Right and left pressure separate adjustable

10.    Coating roller: Right and left pressure separate adjustable

11.    Size(L x W x H)  : 16 x 3.2 x4.5m

Operational Control Panel

Input requirement (provided by the buyer)

Electrical Supply          3 Phase 380 volts 50 Hz , 5 lines or as required
Air Supply                6~8kg/cm2 dry, filtered and regulated
Water Supply              2kg/cm2 Cold water for cooling unit

Technical documents

Operating manual

Install Instruction

Major component instruction

Spare List

Switch                4 sets

Induction Switch        1 set

Kit:                   1 suit
