P8 Outdoor advertising LED Display Screen SMD3535 LED ad board 7500 cd /
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Nichia lamp Large outdoor led display screens SMD RGB waterproof P12.8
-
256 * 256 mm Outdoor SMD LED Display boards PH8mm High BrightnessLED screen
-
Energy saving Full Color P5 Outdoor SMD LED display screen high resolution
-
P12.8 High Definition LED display Screen Nichia chip SMD4540 for Supermarket Mall
-
High Definition Outdoor SMD LED Display advertising P6.25 low power consumption
-
High resolution P8 outdoor LED advertising signs video RGB SMD3535 Nationstar lamp
Product Details
Brand Name | BAKO | Place of Origin | China | |
Model Number | BK-P8 |
Product Description
Certification:CE/ROHS/FCC/SGS
256*256 mm P8? Outdoor? advertising LED Display SMD3535 Nationstar
Specifications:
Unit?module |
Pixel?pitch |
8?mm |
Pixel?density(dots/sqm) |
15625/sqm |
|
LED?encapsulation |
SMD3535 |
|
Driving?method |
1/4 |
|
Module?size(mm) |
256*256mm |
|
Resolution?of?module(?dots) |
32*32 |
|
Major?technical?parameters |
Cabinet?size |
1024*1024mm |
Brightness |
7500cd/?㎡ |
|
Refresh?rate |
>2000HZ |
|
Color?temperature |
6500K |
|
View?angle(H/V) |
160°/140° |
|
Grey?scale |
16bit |
|
Brightness?adjustment |
256?grade/?Manually/?Automatically |
|
Working/?storage?temperature |
-20℃~50℃/?-30℃~60℃ |
|
Working/?storage?humidity |
10%~90%?RH |
|
Working?voltage |
AC220/110V?50Hz |
|
Protect?degree |
IP65/IP54 |
|
MTBF |
>5000h |
|
Life?span |
100000h |
|
Input?Signal |
AV,?S-VIDEO,?VGA,?DVI,?HDMI,?SDI,?DP |
|
Operation?system |
Windows?7/XP |
|
Control?distance |
cat-5?data?cable:<100m,?optical?fiber<15km |
Description:
1. Good waterproof protection: Front is IP65 and back is IP54. There is totally no problem for outdoor application.
2. Big view angle: SMD view angle is bigger than DIP.Its view angle is 160°for horizontal and 110°for vertical.
?
3. Good color uniformity: Since 3 LED chips are encapsulated in one lamp, SMD color uniformity is much better than DIP so the showing effect is perfect.
4. Anti-low temperature: for very cold areas such as Russian market, we should pay special attention to the cold temperature. So we will use anti-low temperature power suppliers and special heat system to warm the display.
?
5. Good heat output system for high temperature: For hot ares, heat output system is specially important. Or else, the whole display will become hot and there will be dangerous. So we help clients to reduce current and also make add fans for screen.
?
6. Energy saving: power consumption is a key factor for LED billboard. BAKO’s LED display is designed with low power consumption to help clients to save energy.?
?
7. High brightness: For outdoor application, brightness is important, especially if the LED display faces the sun directly. BAKO’s outdoor display brightness can be above 7500 nits, completely ensure the requirement for outdoor application.
?
8. Adjustable brightness: To save energy, we will make the LED display\'s brightness adjustable for different environment. For example, in daytime, it will be higher while in the evening, it will be how.
9. Both front and rear service: Front service is more and more popular. BAKO has creative design for front service.
Competitive?Advantage:
1)?48?hours’?ageing?in?factory?before?shipment
2)?on-site?guidance for installation
3)?free?training
4)?full solution?provider
