HT225D Integrated Digital Concrete Test Hammer OLED Display With Software to PC

HT225D Integrated Digital Concrete Test Hammer OLED Display with Software to PC

HT-225D is an integrated digital concrete test hammer which combines data processor and test hammer

into one unit. It is widely used for non destructive testing quality of concrete and building materials in finished

structure or prefabricated blocks. From its rebound value, the compressive strength of con?crete can be

calculated out automatically. All testing data can be stored in memory and transferred to PC by USB cable or

wireless by Blue tooth.

KEY FEATURES

?High contrast OLED display
?All setup can be made on site
?Automatic calculating compressive strength
?Automatic correction of impact direction
?All data will be stored in memory
?All data can be transferred to PC by USB cable or blue tooth(optional)
?Dual display for analogue ruler and digital value

?
Model????????????????????? HT-225D??????????????????????????????????? HT-75D???????????????????????????????? HT-20D
Display??????????????????? OLED digital????????????????????????????? OLED digital????????????????? ? ???? OLED digital
Measuring range????? 10-70N/mm2????????????????????????????? 10-70N/mm2???????????????????????? 1-25N/mm2
Accuracy?????????????????? ±0.1R????????????????????????????????????? ±0.1R????????????????????????? ? ? ? ? ±0.1R
Impact energy???????? 0.225kgm (2.207Nm)for testing???? 0.075kgm (0.735Nm)???????????? 0.020kgm (0.196Nm)
??????????????????????? ? ?? ordinary building and??????????????????? for testing small???????????????????? for testing
??????????????????? ? ? ? ?? bridge construction????????????????????? and impact-sensitive parts of?? mortal or clay of products
????????????????????????????????????????????????????????????????????????????? concrete or artificial brick?????????

Communication USB2.0 or Bluetooth(optional)?
Storage:? data for 4000 concrete structures?
Operating temperature:? -40o-60oC??????
Power supply: ? 3.7V Li-ion rechargeable battery charged via USB port
Dimension (mm):? 280x75x60?
Net weight:? 1.1kg????
?
?
?
