Green 132 Kw Rubber Strainer machine With Electrical Control Cabinet

Description:

The filter Rubber raw material enters the rolling mill to filter away impurities such as scrap iron, stones, etc.

1. Screw made of special steel is with nitrogen treatment, durable.

2. Jacketed type barrel can be cooled for cooling the rubbers effectively.

3. Double head strainer to be quickly and easily exchanged.

4. Smoothly running and high output.

5. Equipped with die-head auto opening system when electric power is cut off.

Applications:

It is used for filtrating the gelled rubber before it enters the calender to ensure the purity of the raw material and protect the calendar from damaging.

Specifications:

I. General Description:

1. Screw Diameter: ￠10″(250mm)

2. Screw Rotate Speed: Max 50 RPM

3. Capacity: 800-1200 kg/hr

4. Main Motor Power: 132 KW DC, 1000RPM,Hangzhou Henli Motor

II. Equipment Component:

1. Screw????????????????????????????????

2. Barrel?????????????????????????????????

3. Double Die Head, Cut Blade??????????

4. Chassis???????????????????????????????

5. Drive Unit????????????????????????????

6. Lubrication and Oil Pressure Unit???? t

7. Electrical Control Cabinet??????????????

8. Piping?????????????????????????????????

III. Detail Specification:

1. Screw 1 Set

(1)￠10″single screw adopt 38CrMoAlA nitrogen treatment. Screw hollow can connect cooling water.?????????

(2) Revolution connection, including stainless steel pipe. Connection adopt domestic famous brand.???

2. Barrel

(1) Type: Jacketed type design, can connect with cooling water.

(2) Material: Outside barrel adopt carbon steel, inside adopt wear proof alloy steel.

(3) Barrel: Die head adopt digital display temperature controller.

3. Die Head

(1) Die head adopt double type, can equipped with jacketed type and can connect with cooling water.

(2) Die head tighten adopt oil pressure method.

(3) Filter board and gasket.

(4) Blade adopts two 2.2KW motor, reduction box and chain drive.

4. Chassis 1 Set

(1) Profile Steel Welding, tempering treatment.

5. Drive Unit 1 Set

(1) Hard surface gear: Including thrust bearing design. Output shaft connect with screw directly. Lubrication adopt splash system. 1 Set

(2) Coupler: Rimmed coupler between motor and reduction gear

(3) Main Motor: 132 KW DC,1000 RPM. Made in Hangzhou Henli.

6. Lubrication and Oil Pressure Unit 1 Set

(1) Bearing Lubrication: Force lubricated by inner motive force inside bearing box.

(2) Oil Pressure Unit:1. Die head clamp and turn on.

2. Including oil tank ,oil pump and accumulator ,can open die head when power cut, easy for cleaning.

7. Electrical Control Cabinet 1 Set

(1) Control cabinet 1 unit, operate table 1 unit, surface spraying plastics treatment.

(2) Start main motor loop
