Product Details
| Brand Name | Hongda | Place of Origin | China | |
Product Description
SWH Series 3D Motion Blender, 150kg Powder Mixing Machine For Electronic, Mining, Metallurgy
Main Application :
This machine is applicable for mixing of powdery and granulate material in pharmaceutical, chemical foodstuff, ligh industry, electronic, mining and metallurgy, national defense industry and scientific research institutes.
Working principle :
This machine is composed of base, governor motor shaft, rotary connecting rod and barrel etc., material barrel is driven by the positive shaft to make complex movement including horizontal move, rotation and roiling etc, which makes the material moved to 3 directions along the barrel, therefore, highly uniform mixing of various material is realized. This machine is a kind of full closed high effcient energy saving mixer without germ and dust. When he material is being mixed, no centrifugal force effect and situation of gravity segregation and laminar accumulation are occurred. In addition, it has larger loading capacity, short mixing time and high efficiency.
Technical Parameters :
|
Model |
Barrel volume? |
Max loading volume |
Max loading weigh |
Mixing time |
Spindle speed |
Motor power |
Overall dimension |
Weight |
|
SWH-10 |
10L |
7L |
7kg |
0-99min |
0-22r/min |
0.18kw |
640*620*55mm |
150kg |
|
SWH-25 |
25L |
18L |
18kg |
0-99min |
0-15r/min |
0.55kw |
900*900*75mm |
150kg |
|
SWH-50 |
50L |
40L |
40kg |
0-99min |
0-15r/min |
0.75kw |
970*950*120mm |
300kg |
|
SWH-100 |
100L |
75L |
75kg |
0-99min |
0-15r/min |
1.5kw |
1200*1600*1500mm |
500kg |
|
SWH-200 |
200L |
160L |
160kg |
0-99min |
0-15r/min |
2.2kw |
1400*1800*1600mm |
800kg |
|
SWH-400 |
400L |
320L |
320kg |
0-99min |
0-12r/min |
4kw |
1700*2100*1850mm |
1200kg |
|
SWH-600 |
600L |
480L |
480kg |
0-99min |
0-11r/min |
5.5kw |
2100*2400*2250mm |
1500kg |
|
SWH-800 |
800L |
640L |
640kg |
0-99min |
0-10r/min |
7.5kw |
2200*2500*2300mm |
