Ione I826 S812 Amlogic TV Box Android 4.4 CE / FCC / ROHS , Internet Television Box

Dimension

119*119*23mm

System Config.

CPU

Amlogic S802 Quad Core up to 2.0GHz(Cortex-A9)

GPU

Octa core ARM Mali-450 up to 600MHz

RAM

DDR3 2GB

ROM

Onboard eMMC Flash 16GB

Bluetooth

BT 4.0

Expand Memory

Micro SD Card (Maximum support 32GB)

Antenna

Built-in antenna for WIFI

Media

Video/Picture Decoding

?? H.265 HP@L5.0 up to 4Kx2K@30fps

?? H.264 HP@L5.1 up to 4Kx2K@30fps

?? H.264 MVC up to 1080P@60fps

?? MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)

?? WMV/VC-1 SP/MP/AP up to 1080P@60fps

?? AVS JiZhun Profile up to 1080P@60fps

?? MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)

?? MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)

?? RealVideo 8/9/10 up to 1080P@60fps

?? H.265 HEVC up to 720P

?? WebM up to VGA

?? Multiple language and multiple format sub-title video support

?? MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)

?? Supports JPEG thumbnail, scaling, rotation and transition effects

?? Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats

Audio format

Support: MP3, AAC, WMA, RM, FLAC, OGG

Communication

Ethernet

10/100M LAN

WIFI

IEEE 802.11a/b/g/n, WiFi compliant

2.400 GHz ~ 2.497 GHz (2.4 GHz ISM Band)

4.900 GHz ~ 5.845 GHz (5.0 GHz ISM Band)

Bluetooth

BT4.0

Sensor/Motor

IR Sensor

1* IR

Indicator

Power LED

1* Power LED with dual color

Interface

Button

1* Power Button

1* Update Button(via one pin hole)

USB2.0

2* Standard USB

1* micro USB with OTG

DC-in

1* DC in Jack

HD IN

1* HD IN Port

HD OUT

1* HD OUT Port

SPDIF

1* S/SPDIF (2CH,? 5.1CH)

RJ45

1* RJ45

SD Card Slot

1* SD card

Accessories

Adapter

1* Adapter 5V 2A

Power cable

1* Power cable

HD cable

1* HD cable

OTG cable

1* OTG cable

IR remote

1* IR remote

QSG

1* QSG

Software Config.
