Smart Slim 36W LED Panel Lighting , Intelligent LED Lighting For Home

Smart LED light panel , intelligent led light for smart house use

Product?Information?

1.? Ultra energy saving, safe and super stable.

2.? Long lifetime: 30000 hours, a two-year warranty.

3.? Leading heat sink design, four light emission instead of backlight emission.

4.? The panel is made of high transparent acrylic board which leads to uniform and soft luminance,?light effects visually closer to natural light.

5.?? Instant start, no flickering, no humming, no buzzing, no glare, No UV or infra-red radiation, no RF interference, no mercury or lead, eco-friendly, no danger of broken

????? glass, conforms to CE and RoHS.

6.?? Special circuit design, each group of LEDs can work separately, avoiding any

?????? problem of lighting output caused by single faulty

7.??? Wide range voltage input: AC 100-240V

8.??? Ultra slim and unlimited design and various dimensions are available.

9.? Optional dimming function.

10.?? High quality light source. The attenuation of SMD LED light source is less than 3% by 3,000hrs aging test under temperature 50 degrees celsius, high luminous

????????efficiency of single LED.

11.?? Advanced high efficiency constant current driver with short circuit protection,

???????? open circuit protection and overload protection.

12.?? Strict?quality?control, lighting?aging?for?24?hrs?and?complete?inspection?before?shipping.

13.??? Solid-state, high shock resistant, strong packaging, convenient to transportation.

14.??? Easy to install, low maintenance cost. Cut cost by reducing re-lamp frequency,

???????? especially in difficult to reach area.

Infraed PIR Switch Discription:

1.To calculate and compare with the infrared ray come from the human body detect from remote infrared sensor, and switch on or off automatic.

2.The induced source is infrared ray from human body (the wave length is 10 micron around), no need sound.

3.It is standby when the light is dark or dim, and it is dormant during the day time.

Infraed PIR SwitchTechnical Parameter:

1. working voltage: AC175V~250V? 50Hz

2. power: LED<=80W

3. induced distance: 5~8m

4. Left-right115° up-down110°Induced angle: horizontal 115 degree, vertical 110 degree

5.delay time: 60S+_20S

6. brightness sensitivity: 6Lux+_2Lux

Specifications:
