220V 50Hz DSP Pure Sine Wave UPS 4800W 6Kva Onlne UPS Power Supply

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	UPSEN		Place of Origin	China
Model Number	Queen Star Series 6-20Kva

Product Description

Delivery Time:7-15 Days
Certification:CE, ISO, RoHS

220V 50Hz DSP Pure Sine Wave UPS 4800W 6kva Online UPS Power Supply Inbuilt 16pcs Batteries 12V 7Ah?????????????????????????????????

Model: High Frequency Online UPS Queen Star Series 6-20?Kva (1ph in/1ph out)?

Key Features:

● True online double conversion technology, Pure Sine Wave Output
● 0.8 Output Power Factor, Digital LCD Screen, Zero transfer time ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

● DSP Technology, ?compact design? ? ? ? ? ? ?
● Active input power factor correction (PFC)
● Protection against all types of power problems
● Wide range of input voltage and frequency
● Active Load Management, cold start function
● Sufficient Expansion Slots for USB,AS400,CMC monitoring,SNMP,RS485 and EMD environmen monitoring?
● Equipped with maintenance bypass switch
● Generator Supportable
● Sealed lead acid, maintenance free battery

Technical Specification

Queen Star Series Q6K-20Kva
Model	Q6K	Q6KL	Q10K	Q10KL	31Q10KL	31Q15KL	31Q20KL
Capacity	6KVA/4800W	10KVA/8000W	15KVA/12KW	20KVA/16KW
Input	Nominal Voltage	220/230/240Vac	380/400/415Vac
Voltage Range	176~276Vac (1P2W+G)	304~478Vac (3P4W+G)
Current?	31A (max)	50A (max)	50A (max)	75A (max)	100A (max)
Frequency	46~54Hz/56~64Hz
Power Factor	≥0.99
Output	Voltage	220/230/240± 2%Vac? (1P2W+G)
Frequency	50/60Hz(adjustable)????????????????????????????????????????????????????????????????????????????????????? 50/60Hz± 5% (Line mode) 50/60Hz ± 0.05Hz ( Battery mode)
Current?	27.3A	45A	68A	91A
Power Factor	0.8lag
Waveform	Pure Sine Wave
Waveform Distortion	Line load ＜2%	Line load ＜3%
Back-up Time	Full Load	≥7′	Depends on external batteries bank\'s Capacity	≥5′	Depends on external batteries bank\'s Capacity
Half Load	≥20′	≥13′
Battery Nominal Voltage	192/240Vdc
Transfer Time	0ms
Overload Capacity	?＞105% 1min, ＞120% 30s transfer to bypass, shut down in 1min
Communication	SNMP,RS-232,USB+Intelligent Slot
Operating Environment	Temperature	0C~40℃
Humidity	15%~90%
Dimension	Width (mm)	260	260	260	260	260
Depth (mm)	560	533	560	533	560
Height (mm)	717	501	717	501	717
Net Weight(Kg)	68	18	70	20	28	30	30
*Specification are subject to change without prior notice
