Proximity Card or PIN CODE single door access control systems

Proximity Card or PIN CODE single door access control systems

Normal, Secure,& Master Users
The 7612 accepts up to 500 users and provide entry via two codes: Memory Slot 1(Primary code) and Memory Slot 2(Secondary code).

There are three user levels:
? Normal User
A Normal User only has a Primary Code and is only granted access when the IBA-761 is in Normal Mode.
? Secure User
A Secure User must have a Primary and Secondary code programmed, the two codes must not be the same. the Secure User can gain access when 7612 is in its two Modes of Operation. In normal Mode the Secure User must present both their Primary and Secondary Codes in order to gain entry.
? Master User
A Master User must have both Primary and Secondary code programmed with the same Proximit Card or PIN code. The Master user ca gain access during any Mode of Operation by presenting their Proximity Card or PIN CODE to the controller.(The master user is convenient but is less secure than a Secure User).

Primary code and Secondary code
Primary code:
1)Only can be used separately under the mode of Normal
2)Can\'t be same with the other codes

Secondary code:
1) Must match the corresponding Primary Code in Secure Mode
2) Don\'t be same with the System Code (i.e. Factory settings), but the different users can set the same

Secondary code.
Normal Mode and Secure Mode

Specifications:

Construction

code search Feature that helps make maintaining user codes easier.
Built-in Case and Back Tamper Bell, Chime, Siren, Battery Backup, Tamper Output features available with IBA Power Supplies.
Programmable Siren Time.
Programmable Lock Strike Release Time.
?
