Anti-fire Fabric 27oz 1mm Pva Coated Fireproof Fiberglass Fabrics for Welding Protection
- shnaghai or any port in china
- T/T Credit Card
You May Like
-
Aarmid FR Ripstop Fabric FIRE RETARDANT Fabric
-
Aramid Fireproof Fabric for Workwear Permanently FR Fabric for Safety Garment
-
2014 New Good Quality Inherently Flame Retardant Aramid Fabric for Sale for Firefighter
-
100% PTFE Membrane Laminated Waterproof Fire Resistant Fabric, Fireproof Fabric For Workwear Clothes
-
Aramid Fabric, FR Fabric/aramid Uniforms Alternative/EN 11612,NFPA2112
-
Bullet Proof Aramid Fiber Ballistic Fabric Aramid Anti-static Fabric for Coveralls/overalls(aramid)
Product Details
| Place of Origin | Henan, China | Brand Name | Drotex | |
| Application | Fiberglass Mesh Cloth | Weight | 27oz | |
| Surface Treatment | EPDM Coated | Width | 100-200cm | |
| Weave Type | Twill Woven | Yarn Type | C-Glass | |
| Alkali Content | Alkali Free | Standing Temperature | 5500C |
Product Description
Weave-lock finished fiberglass fabrics
The weave-lock treatment stiffens the fabric slightly to reduce the amount of fraying during fabrication. The weave-lock finished fiberglass fabric enables the user to cut, sew and punch holes more effectively.
Main applications:
-Hullboard.
-Welding blankets
-Fire doos/Fire curtains
-Other fire control systems
DESCRIPTION |
| |||
TGF880-AC225-3008 is a medium weight texturized fiberglass fabric, acrylic weave set finish- high add-on, provide good hand, minimal dust, and ease of application. It’s used for flexible expansion joint, removable jackets, welding protection and other types of fire control systems. | ||||
| ||||
BASE FABRIC | Base fabric style No. TGF880 | |||
| (Metric) | (English) | Test methods | |
Weave | 4 harness satin | Crowfoot |
| |
Yarn |
|
|
| |
Warp | ET9 480 tex | ETG 8.6 |
| |
Weft | ET9 480 tex | ETG 8.6 |
| |
Construction |
|
|
| |
Warp | 10 ± 0.6 ends/cm | 25 ± 2 ends/inch | ASTM D 3775-96 | |
Weft | 8 ± 0.5 picks/cm | 20 ± 1 picks/inch | ASTM D 3775-96 | |
Weight | 880 ± 40 g/m2 | 25.8 ± 1.2 oz/yd2 | ASTM D3776-96 | |
Thickness | 1.0 ± 0.1 mm | 0.039 ± 0.005 inch | ASTM D1777-96 | |
|
| |||
COATED FABRIC | Coating style No. AC225-3008 | |||
Coating | Acrylic weave-set finish on both sides, high add-on. | |||
Weight | 910 ± 40 g/m2 | 27 ± 1.2 oz/yd2 | ASTM D3776-96 | |
Thickness | 1.05 ± 0.1 mm | 0.043 ±0.005 inch | ASTM D1777-96 | |
Color | Black |
| ||
Temp resistance | 5500C | 10000F |
| |
