Steady , synchronous Pier formwork , Shoring Tower Climbing Formwork hydraulic system

Steady , synchronous and safe Auto Self Climbing Formwork QPMX-50

Descrition:?

The?lifting?power?of?the?Formwork?QPMX-50?comes?from?its?hydraulic?system,?which?includes?the?oil?cylinder?

and?commutator.?Through?functioning?of?hydraulic?system,?the?steel?rail?and?bracket?can?climb?up?alternately,?

so?the?whole?formwork?system?climbs?steadily,?independent?of?a?crane.?It\'?s?easy?to?operate,?and?climbing?is fast?and?safe.

Structure?

The?Characteristics?

1.?One?oil?cylinder?unit?can?lift?50KN.
2.?The?QPMX-50?system?can?climb?not?only?vertically?but?also?slantwise,?and?the?forward?or?backward?inclination?

can?be?up?to?18?degrees.
3.?The?system?can?climb?up?wholly?or?separately.?The?climbing?process?is?steady,?synchronous?and?safe.
4?.The?bracket?does?not?come?back?to?the?ground?until?construction?work?is?finished,?and?spacing?for?work?is

?reduced while?the?bumping?damage?is?almost?completely?prevented,?especially?for?the?plywood.
5．The?error?of?structure?construction?is?tiny?and?easy?to?correct.
6．The?formwork?can?climb?up?by?itself?and?cleaning?work?can?be?done?in?situ.?The?number?of?crane?lifts?are?

greatly?reduced.

Standard?Climbing?Process?

1. Set?up?the?formwork?by?wall-through?tie-rods?and?pull-push?props,?embed?anchors?and?do?the?first?concrete?

pouring.
2.? Remove?the?formwork?after?the?first?pouring?and?fix?anchor?shoes?on?the?finished?wall,?lift?the?brackets?and?

formwork

?to?the?right?position,?match?the?formwork?and?do?the?second?pouring.
3. Lift?formwork?and?brackets?to?the?higher?floor;?fix?climbing?rail?and?hydraulic?system.
4. Match?the?formwork?to?the?right?position?and?do?the?third?pouring.
5. Strip?the?formwork?and?fix?anchor?shoes?on?the?finished?wall,?then?let?the?climbing?rails?climb.
6.?Brackets?climb?up?to?the?right?position,?then?install?suspended?platform.
7. Match?the?formwork,?do?the?concrete?pouring,?and?proceed?into?the?standard?climbing?stage.
?
