Product Details
| Brand Name | WEDFV | Place of Origin | China | |
| Model Number | ISC-1212-I |
Product Description
Multiple data format 115.2Kbps Industrial RS-422 / 485 repeater Media Converter with 3KV isolation
Industrial RS-422/485 repeater with 3KV isolation
Features
Automatic internal RS-422/485 bus supervision Support Full-Duplex transmission for RS-232/RS-422 RS-232/RS-422 support RTS/CTS handshake signals Supported baud rate up to 115.2Kbps Reach distance up to 4000 feet (1200m) Support multiple baud rate and multiple data format Reserved space for termination resistors (R8,R9) Power and data flow indicator for troubleshooting Power requirement : +9 ~ 30VDC Din-Rail and wall mounting enabledISC-1212-I
Industrial RS-422/485 repeater with 3KV isolation
Introduction
The ISC-1212-I is a RS-422/485 repeater which boosts the RS-422/485 signals to extend the reach distance up to 4000 ft (1200m) and increase the maximum number of connection up to 128 nodes. With a special circuitry, ISC-1212-I is able to automatically detect the data flow and switch the direction of the data lines accordingly. “Auto baud rate detector” enables ISC-1212-I to automatically configure RS-422/485 signals to any baud rate without external
switch setting. Build in opto-isolations on ISC-1212-I provides 3000VDC of isolation to protect the host computer from destructive voltage spikes on the RS- 422/485 data lines. ISC-1212-I also offers internal surge-protection on the data lines. The internal high-speed transient suppressors on each data line protect the module from dangerous voltages levels or spikes. Therefore, the ISC-1212-I is a reliable RS-422/485 repeater and can satisfy most demand of operating environment.
