Economical PU Sandwich Panel Machine With Tracking Cutting for PU Wall Panel
- T/T L/C D/P D/A
- 7 days
You May Like
-
Glazed Steel Plate Wall Cladding Roof Panel Roll Forming Line with PLC Controller
-
Aluminium PBR / PBU Roof Panel Roll Forming Machine with Manual Uncoiler
-
5.5 KW Eaves Trim Ridge Flashing Roof Panel Roll Forming Machine with 10 Stations
-
Ridge Flashing Roof Panel Ridge Cap Roll Forming Machine 550 MPa Yield Strength
-
7.5 KW Chromedeck Roof Panel Roll Forming Machinery with 70 mm Shaft Diameter
-
7.5 KW Boltless Metal Roof Panel Roll Forming Machine with Hydraulic Driving
Product Details
| Brand Name | RISHBIN | Place of Origin | China | |
| Model Number | RH-PU-17 |
Product Description
Certification:CE
Economical PU Sandwich Panel Machine With Tracking Cutting for PU Wall Panel
Technical parameters of?PU?sandwich panel machine
| Item | Specification |
| Type of material | Colcor steel sheet;galvanized sheet,aluminum sheet |
| Thickness of material | 0.4-0.8(mm) |
| Width of material | Max1250mm |
| Length of panel | 2000-16000(mm) |
| Width of panel | 600-1200(mm) |
| Thickness of panel | 30-200(Not including height of corrugation)(mm) |
| Production speed | 3-8(Adjustable)(m/min) |
| Valid length of double belt conveyor | 16000-36000(mm) |
| Work pressure on pouring foam | 150-200(Bar) |
| Total power | about 300KW |
| Total size(L*W*H) | 130000*15000*6000(mm) |
Hydraulic shearing?of?PU?sandwich panel machine
|
Material?of?blade |
Cr12,heat?treatment?60-62°C |
|
Shearing?system |
The?system?includes?a?set?of?hydraulic?tank,?a set?of?hydraulic?oil?pump,?two?hydraulic?pipes. And?two?sets?of?electromagnetism?valves. It is?controlled?by?gear?wheel?oil?pump.?After filling?the?hydraulic?oil?into?the?hydraulic?oil?tank, the?pumps?drive?the?cutter?machine?to?begin?the cutting?job. Power?of?the?oil?pump:?3kw Hydraulic?oil?:40# |
The chart of process flowing?
Decoiling—active feeding (put the coil strip into the first feeding roller)—leveling —roll forming —
computer control system—hydraulic cutting—product to stand
Company introduction
?
Rishbin?was founded in 1999. With more than ten years\' development, now it becomes a leading professional supplier in the field of?roll forming machinery?industry, and exports its quality production line to the markets all over the world.
?
we?are?one?of?the?leading?suppliers?and?manufacturer?in?china?and?have?been?supplying?and?making?roll?forming?equipment?for?the?metal?building?construction?industry?for?a?long?time.
