Automobile VAG Diagnostic Tool Vagtacho USB V 5.0 VAG Tacho For NEC MCU 24C32 or 24C64

Vagtacho USB ?V 5.0 VAG Tacho For NEC MCU 24C32 or 24C64

Note:

1.Lastest version 5.0

2.TP22,23,24,25 transponders are required!

VAG Tacho USB Version V 5.0 support VDO with 24C32 or 24C64,our vagtacho usb version 5.0 includes the functions of vagtacho usb 4.52 , vagtacho usb 4.0, and vagtacho usb 3.5,VAG Kombiinstrument / Immo box eeprom programmer

Description:

Support VDO with 24C32 or 24C64,our vagtacho usb version 5.0 includes the functions of? vagtacho usb 4.52 , vagtacho usb 4.0, and?vagtacho usb 3.5
VAG Kombiinstrument / Immo box eeprom programmer
Windows 7, Vista, Win XP, Win 98 compatible software

Support for some VDO dashes for VW from year 2009-2011 with NEC mcu and 24C32 or 24C64 eeprom memory. Important: These dashes requires ignition to be switched on with valid key of the car! Software version 5.0 works ONLY with interfaces which has got built-in programmer for Megamos ID48 transponders!

Built-in programmer for Megamos ID48 transponders! Pre-programming of TP2x transponders as dealer\'s keys with component security data which is read from immobiliser!
NEW key programming feature for VAG cars with VDO dashes on CAN bus! (TP2 and UDS protocols)

List of supported VAG cars:

Volkswagen
Golf 6, Jetta, Polo, EOS with VDO dash 2009 - 2011, note: not all dashes are supported!
Golf 5, Caddy, Touran, Jetta, EOS with VDO dash 2003 - June.2006
Golf 4, Bora with VDO or Motometer/Bosch dash: 1997-2003
Beetle with Marelli dash: 1998 - 2005
Passat, Jetta, with VDO, Marelli or Motometer dash: 1997-2004
Polo with VDO or Motometer dash: 1999-2006 (1999-2002 mileage change only)
Sharan with VDO dash: 2000-2004(mileage change only)
Caddy, Lupo with VDO or Motometer dash 1997 - 2002(mileage change only)
Transporter with VDO dash 1998 - 2000
LT35 ( Temic immo box) 1999-2003 (pin code read only)
Gol ( Kostal immo box) 1999-2003 (pin code read only)

Seat
Altea, Leon, Toledo with VDO 2003 - 6/2006
Leon, Toledo, Cordoba, Ibiza with VDO or Motometer dash 1997-2003
Alhambra with VDO 2000 - 2004(mileage change only)
Inca with VDO or Motometer 1997 -2000(mileage change only)

Skoda
Octavia II with VDO dash 2005 - 6/2006
Octavia, Fabia with VDO dash 1997 - 2004

Audi
A3 VDO dash 2003 - 2005
A3,A4,A6 VDO dash 1997 - 2000
A3,TT,A6 Magnetti Marelli dash 1998 - 2003
A4 Bosch dash 2000 - 2008 - Read/write of encrypted data with V4.5!
A4,A6,A8 1995-1999 (immo box - read pin code)

Vag tacho usb version 4.52

Vagtcho 4.52 is upgraded from vag tacho usb4.0, Upgrade Vagtacho usb 4.0 interface with Programmer for Megamos ID48 chips, our vagtacho version 5.0 has upgraded directly ,includes the functions for vagtacho usb 4.52
The benefits with this upgrade are:
Your Vagtacho interface will works with software vesrion 5.0 for the new VDO dashes with UDS protocol from year 2009+
Programming of new keys to VAG cars which are into FAZIT database.
Works with cars which has got locked key programming channel, or pin code is not accepted.
No need to wait up to 30 minutes for the key programming procedure.
With this upgrade, Vagtacho can program the new key in one minute

Vagtacho version 4.0

?VAG Kombiinstrument / Immo box eeprom programmer!
?Windows 7, Vista, Win XP, Win 98 compatible software!
? Works on any computer which has got USB port!
? Most of VAG dashes from 1997 to 2006 are supported!
? Direct programming of Megamos ID48 (JMA-TP08) chips to VAG cars on CAN bus from November 2003 to June 2006
? Transponder Maker Pro is required for pre-programming of these chips.
???Note: TP22,23,24,25 transponders are NOT required!

1.Main functions:
?
? Read ecu info
? Read pin code
? Change mileage
? Read eeprom
? Programmer new key
? Write eeprom
? Clear ecu errors
??Viem memory buffer
?
2.List of supported VAG cars:
?
Volkswagen
?Golf 5, Caddy, Touran, Jetta, EOS with VDO dash 2003 - June.2006
?Golf 4, Bora with VDO or Motometer/Bosch dash: 1997-2003
?Beetle with Marelli dash: 1998 - 2005
?Passat, Jetta, with VDO, Marelli or Motometer dash: 1997-2004
?Polo with VDO or Motometer dash: 1999-2006 (1999-2002 mileage change only)
?Sharan with VDO dash: 2000-2004(mileage change only)
?Caddy, Lupo with VDO or Motometer dash 1997 - 2002(mileage change only)
?Transporter with VDO dash 1998 - 2000
?LT35 ( Temic immo box) 1999-2003 (pin code read only)
?Gol ( Kostal immo box) 1999-2003 (pin code read only)
?
Seat
?Altea, Leon, Toledo with VDO 2003 - 6/2006
?Leon, Toledo, Cordoba, Ibiza with VDO or Motometer dash 1997-2003
?Alhambrawith VDO 2000 - 2004(mileage change only)
?Inca with VDO
