7.0" TFT Touch Screen LCD Module with 4-Wire Resistance

Brand Name	sooboo		Place of Origin	China
Model Number	H-B070D-12AO

Hello! Welcome to Senboo!

1.1 Introduction
Display model H-B070D-12AO is a color active matrix thin film transistor(TFT) liquid Crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is Composed of a TFT LCD panel, a driving circuit and a back light system. This TFT LCD has a 7.0 (16: 9) inch diagonally measured active display area with WVGA (800 horizontal by 480 Vertical pixel) resolution.

1.2 Features
7.0 (16: 9 diagonal) inch configuration.
6 bits + FRC driver with 1 channel TTL interface
LED Backlight
Up/Down, Left/Right reversion selection

1.3 Applications
Mobile NB
Digital Photo frame
Multimedia applications and Others AV system

LCD Type: TFT
Display color: 262k
Viewing Direction: 6 Clock
Operating temperature: -20~+70º C
Storage temperature: -30~+80º C
Module size: 164.90 (W)x 100.00(H) x 3.55 (D) mm
Display Area(W× H): 154.08(H) x 85.92(V) mm
Number of Dots: 800 x 3RGB x 480 Dots
Power Supply Voltage: 2.8 V
Outline Dimensions: Refer to outline drawing
Backlight: LED Side-light type
Weight: ~100g
Interface: F. P. C 0.5mm

Note 1: Color tune is slightly changed by temperature and driving voltage.
Note 2: Without FPC and Solder.

Precautions for Use of LCD Modules
1 Handling Precautions
1.1 The display panel is made of glass. Do not subject it to a mechanical shock by dropping it from a high place, etc.
1.2 If the display panel is damaged and the liquid crystal substance inside it leaks out, be sure not to get any in your mouth, if the substance comes into contact with your skin or clothes, promptly wash it off using soap and water.
1.3 Do not apply excessive force to the display surface or the adjoining areas since this may cause the color tone to vary.
1.4 The polarizer covering the display surface of the LCD module is soft and easily scratched. Handle this polarizer carefully.
1.5 If the display surface is contaminated, breathe on the surface and gently wipe it with a soft dry cloth. If still not completely clear, moisten cloth with one of the following solvents:
A. Isopropyl alcohol
B. Ethyl alcohol
Solvents other than those mentioned above may damage the polarizer. Especially, do not use the following:
A. Water
B. Ketone
C. Aromatic solvents
1.6 Do not attempt to disassemble the LCD Module.
1.7 If the logic circuit power is off, do not apply the input signals.
1.8 To prevent destruction of the elements by static electricity, be careful to maintain an optimum work environment.
A. Be sure to ground the body when handling the LCD Modules.
B. Tools required for assembly, such as soldering irons, must be properly ground.
C. To reduce the amount of static electricity generated, do not conduct assembly and other work under dry conditions.
D. The LCD Module is coated with a film to protect the display surface. Be care when peeling off this protective film since static electricity may be generated.

2 Storage precautions
2.1 When storing the LCD modules, avoid exposure to direct sunlight or to the light of fluorescent lamps.
2.2 The LCD modules should be stored under the storage temperature range. If the LCD modules will be stored for a long time, the recommend condition is:
Temperature: 0 ~ 40º C
Relatively humidity: ≤ 80%
2.3 The LCD modules should be stored in the room without acid, alkali and harmful gas.

3 The LCD modules should be no falling and violent shocking during sportation, and also should avoid excessive press, water, damp and shine.
