Home > Products > SFP + Optical Transceiver > SFP+ Optical Transceiver 10G 850nm SR 300M Cisco Compatible

SFP+ Optical Transceiver 10G 850nm SR 300M Cisco Compatible

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Supply Ability 0 Unit / Units per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	GB-Link/OEM		Place of Origin	China
Model Number	GB-SFP+-SR

Product Description

Delivery Time:1~3 working days
Certification:UL, CE,ROHS, FCC, TUV
10Gb/s 850nm Multi-mode SFP+ Transceiver

Quick Detail:

Product part Number

Data Rate

(Gbps)

Media

Wavelength

(nm)

Transmission

Distance(km)

Temperature Range(Tcase)(℃)

GB-SFP+-SR

10G

Single mode fiber

850

300M

0~70

commercial

Description:

GB-LINK GB-SFP+SR transceivers support the 2-wire serial communication protocol as defined in the SFP+ MSA.

The standard SFP serial ID provides access to identification information that describes the transceiver’s capabilities, standard interfaces, manufacturer, and other information.

Additionally, GB-LINK SFP+ transceivers provide a unique enhanced digital diagnostic monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage. It also defines a sophisticated system of alarm and warning flags, which alerts end-users when particular operating parameters are outside of a factory set normal range.

The SFP+ MSA defines a 256-byte memory map in EEPROM that is accessible over a 2-wire serial interface at the 8 bit address 1010000X (A0h). The digital diagnostic monitoring interface makes use of the 8 bit address 1010001X (A2h), so the originally defined serial ID memory map remains unchanged.

Applications:?

?10GBASE-LR/LW & 10G Ethernet?

Specifications

PRODUCT FEATURES

Up to 11.1Gbps Data Links Up to 10km transmission on SMF DFB Laser and PIN receiver Metal enclosure, for lower EMI 2-wire interface with integrated Digital Diagnostic monitoring Hot-pluggable SFP+ footprint Specifications compliant with SFF 8472 Compliant with SFP+ MSA with LC connector Single 3.3V power supply Case operating temperature range:0°C to 70°C? Power dissipation < 1.5 W

Competitive advantage:
?

High reliability and consistency Good pricing Full compatible (CISCO/HP/Extreme/Juniper/H3C…) OEM/ODM? Customized label? Fast delivery
