SFP+ Optical Transceiver 10GBASE-ER 1550nm 40KM
- T/T L/C D/P D/A
- 7 days
You May Like
-
SFP+ Optical Transceiver 10GBASE-LRI 1310nm 10km I - Temp
-
SFP+ Optical Transceiver 10GBASE-LRM 1310nm 10km I - Temp
-
SFP+ Optical Transceiver 10G 850nm 300M Multi - Mode I - Temp
-
SFP+ Optical Transceiver 10GBASE-ZR 1550nm 80KM
-
SFP+ Optical Transceiver 10GBASE-ZR 1310nm 80KM Cisco Compatible
-
SFP+ Optical Transceiver 10G 850nm SR 300M Cisco Compatible
Product Details
| Brand Name | GB-Link/OEM | Place of Origin | China | |
| Model Number | GB-SFP+-ER |
Product Description
Certification:UL, CE,ROHS, FCC, TUV
10Gb/s 1550nm SFP+ 40kmTransceiver
Quick Detail:
|
Product part Number |
Data Rate (Gbps) |
Media |
Wavelength (nm) |
Transmission Distance(km) |
Temperature Range(Tcase)(℃) |
|
|
GB-SFP+-ER |
10G |
Single mode fiber |
1550 |
40 |
0~70 |
commercial |
Description:
GB-LINK GB-SFP+31ER transceivers support the 2-wire serial communication protocol as defined in the SFP+ MSA.
The standard SFP serial ID provides access to identification information that describes the transceiver’s capabilities, standard interfaces, manufacturer, and other information.
The transceiver consists of two sections: The transmitter section incorporates a DFB laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.?
Applications:?
10GBASE-ER/EW & 10G EthernetSpecifications
PRODUCT FEATURES
Up to 11.1Gbps Data Links Up to 40km transmission on SMF EML transmitter and PIN receiver Metal enclosure, for lower EMI 2-wire interface with integrated Digital Diagnostic monitoring Hot-pluggable SFP+ footprint Specifications compliant with SFF 8472 Compliant with SFP+ MSA with LC connector Single 3.3V power supply Case operating temperature range:0°C to 70°C? Power dissipation < 1.5W
Competitive advantage:
?
