150Mbps wireless repeater module

Model Number: WRT-10
Product Introduction
WIFI Repeater is designed as an ideal solution to weak Wi-Fi or wired only connection at your home or in a hotel room. With the router plugged in, a secure Wi-Fi hotspot for all your Wi-Fi enabled devices is instantly established. The device allows you to conveniently connect to the internet in different scenarios. this compact device is the perfect choice for domestic, business to work or play.

Product Features
Portable design and built-in power adapter, ideal for travel and home use
Transmission signal stability
It have good penetration, it can transmit over 10m after 2 walls.
It release wifi signal after connect with dynamic IP network cable, or wireless router.
It enhanced the range of the signal cover

Product Specifications
Model
WIFI Repeater
Wireless Standards
IEEE 802.11n, IEEE 802.11g,IEEE 802.11b,CSMA/CA with ACK
Frequency
2.4~2.4835GHz
channel
1-14
Spread Spectrum
802.11 g/n: OFDM
802.11b: CCK(11, 5.5Mbps), QPSK(2Mbps), BPSK(1Mbps), DSSS
Signal Rate
802.11b: 11,5.5,2,1 Mbps
802.11g: 54,48,36,24,18,12,9,6 Mbps
802011n: 150Mbps
Reception Sensitivity
130M: -65dBm@10% PER; 108M:-65dBm@10% PER; 54M:-65dBm@10% PER; 11M:-87dBm@8%PER; 6M:-90dBm@10% PER; 1M:-90dBm@8% PER
Transmit Power
16dBm(max)
Antenna
3dbi
voltage
AC 90-240V
USB port Output
DC 5V 1A
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
System Requirements
Windows 2000/XP/Vista/WIN 7/WIN CE/LINUX/MAC OS
