Wireless 4 Camera Security System with DVR , High Resolution Security Camera Set

Compression formart

H.264

Video?System

NTSC?/?PAL

Operation?System

Linux?Based

Video?Input?/?Output

BNC?4-Channel?Input?/?1-Channel?Output

Other?Video?Output

VGA/HDMI

Audio?Input?/?Output

RCA?2CH

Display?Resolution

NTSC:?960H(?960X576?)?/?PAL:?960H(?960X576?)

Recording?Frame?Rate

NTSC:?120?fps?@4CH?960H;/?PAL:?100?fps?@4CH?960H

Record?Resolution

Selectable:?NTSC:?960H(?960X576?);D1(704?x?480);?CIF?(352?x?240)?/??

PAL:?960H(?960X576?);D1(704?x?576);?CIF?(352?x?288)

Record?Mode

Continuous?/?Time?Schedule?/?Motion?Detection

Network?Function

Support?Live?View?with?IE?&?Mobile?Phone

Network

RJ45,?10M/100M

Net?Protocol

TCP/IP,?PPPoE,?DHCP?and?DDNS

Remote?Access

LAN?or?Internet?Browsing

PTZ?Control

RS-485

HDD?Interface

SATA?II/III,?Support?between?320GB?and?2TB,?(Not?Includes)

USB

USB?Backup/USB?2.0

Remote?Control

IR?Remote?Control

Power?Supply

DC12V,?2.5A

?Resolution

?600 / 700TVL

Device Sensor

?1/3\"?Color?CMOS

Effective?Pixels

976(H)*596(V)

TV?System

NTSC?/?PAL

Lens

3.6 /6mm for optional

Number?of?IR?LEDs

24?LEDs

IR Distance

up?to?65ft

Minimum?Illumination

0.0?Lux

S/N?Ratio

>?48dB

Video?Output

1.0Vp-p,?75ohms

Operating?Temperature

-25°F~122°F?/?-32°C?~50°C

Weatherproof

Yes

Power

12V?DC

Material

Metal?Shell
