Galvanized Steel CE / ISO9001 2008 High Speed Roll Up Door Single-Three Phrase

Galvanized Steel CE / ISO9001 2008 High Speed Roll Up Door Single-Three Phrase

Specifications:

Technical Parameter for speed door

Max Size:3500mm(W)*3500mm(H)

Opening Speed:1.5m/s

Closing Speed:1.0m/s

Wind load Max:10m/s

Mechanical Unit

Frame:304 Stainless Steel/Aluminum

Inner Frame:2.0mm Stainless Steel/Galvanized Steel

Thickness of frame:2.0mm Stainless Steel

Thickness of shaft cover:1.5mm 304 Stainless Steel/Galvanized Steel

Motor cover:Yes

Frame Size:100mm*60mm

Control Unit

Control system

Control Box Size:320 X 400 X 210 mm

Driving System

Feature:Absolutely Encoder

Driving Unit Brand:ABB Motor / Yaskawa Frequent Convert

Activation System

Open and Close the door:

Safety System

Safe Equipment:

Description:

With more than ten years of rich experience, Suncome, a combination supplier of special industrial doors and loading/unloading system as well as an entrepreneur for the solution of logistics system,is the best choice of high-efficiency and energy?savings in modern architectures and factories.

Our products are widely used in many fields such as food, pharmacy, chemical industries, electronics, auto manufacturers, precision machineries, clean rooms, refrigeration industries, intelligence building, automatic parking system, integrate with Europe advanced technology, notion, especially with high quality, affordable price, safety and durability.

We boast professional sales engineers, installation teams and after-sales service personnel who can provide our clients with customized service .

Automatic and High Performance Speed Door ?is the solution to the high-level?clean environment which needs prevent dust and anti-bacteria, applied in the busy passageway area with high clearness demands,strong wind-resistance,especially for the food,pharmacy, and fine machining industry.

1) Special design for factory’s outside application
2) high frequent using of the outside logistics demands.
3) High speed auto opening and closing for the logistics transferring.
4) Quick reaction by the controlling of the activation way.
5) Auto time-delayed function adjustment based on good transferring time.
6) Sustained innovation on the product.
7) Energy saving for the temperature difference.
8) High efficient for the door operation.
9) Adopting “Absolutely Encoder” to avoid the top and end position readjusting after the power off.
10) Unique Man-Machine Interface to ensure the smooth operation. Error shooting function is also a tool for engineer to find the key of problem shortly.
11) Door controlling system is easy to meet the different demands.
12) Standard activation terminals are equipped with the control system to avoid trouble when the door’s opening and closing way changed.
13) Unique design and innovation on “Main Board”.
14) One-Key push button to Up and Down the door manually.
15) RED EMERGENCY STOP push button for “STOP” function in Emergent status.
16) High Frequent Motor with auto-brake function.
17) Anti-rusty 304 stainless steel suits for the cleaning environment application.
18) Unique inner Nylon molded frame and double lines brus
