Double Cage Construction Material Hoist 1600kg , Man and Material Hoist
- T/T L/C D/P D/A
- 7 days
You May Like
-
1.6T Construction Elevator Vertical Rack and Pinion Hoist 3 1.4 2.5m
-
Window Cleaning Equipment Suspended Access Platform / Mobile Access Platforms
-
Electric Construction Working Rope Suspended Platform for Bridge / Building
-
Industrial Elevators and Lifts Cage Hoists , Passenger and Material Hoisting Machinery 1600kg
-
Red / Blue Customized Industrial Elevators With Galvanized High efficiency
-
Painted Industrial Lift 2000kg 3 1.3 2.5 m , Building Material Handling Hoist
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | SC-series |
Product Description
Certification:CE,ISO
Dol / FC Construction Material Hoist 1600 Double Cage With 22m / min Rated Lifting Speed
Quick Detail:
|
Name |
Other?Name |
Brand?Name |
Control |
|
Construction?Hoist |
Construction?Hoist?SC?160/160 |
BORUIDA |
DOL?and?FC |
|
Loading?Capacity |
1600kg/1600kg |
Certificate |
CE |
Description:
Construction Hoist SC 160/160 is installed and dismounted conveniently and can grow as high as the building grows height.The construction Hoist has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.It is efficient and safety vertical transporting equipment
Applications:
SC serialization of products construction Hoist is a Rack and Pinion EL. Construction Hoist widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.?
Specifications
Standard?technical datas of? double cages:
|
Parameter |
SC100/100 |
SC160/160 |
SC200/200 |
SC270/270 |
SC320/320 |
|
Rated |
1000/1000 |
1600/1600 |
2000/2000 |
2700/2700 |
3200/3200 |
|
Rated?lifting?speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated?passenger?number |
12/12 |
18/18 |
24/24 |
30/30 |
38/38 |
|
Max.?lifting?height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine?power(kW) |
2*2*9.5 |
2*2*11 |
2*2*13 |
2*3*18.5? |
2*3*22 |
|
Cage?inner?dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Cage?weight?(kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast?section?weight |
145 |
145 |
163 |
163 |
163 |
|
Mast?section?dimension?(mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety?device?type |
?SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
SAJ40-1.4? |
SAJ50-2.0? |
|
Hanger?rated?lifting?capacity |
250 |
250 |
250 |
250 |
250 |
|
Rack?module |
8 |
8 |
8 |
8 |
8 |
SC series?construction hoists:?
1). Cage load capacity: 1000kg~3200kg;
2). Lifting speed:33m/min, 0~40m/min;0~60m/min;
3). Increased lifting height on request;
4). Mast section: Painted or hot dipped zinc?
5). Cage:double cage?
6). Recommended cage inner dimensions (L*W*H): 3*1.
