GPS tracker , Car alarm system, vehicle GPS track device

Size

137*78*29mm

Working Voltage

DC:6.3~40V

Input Fuse

5A

Working Temperature

-40~85°C

Humidity

10% to 90%

CPU

TI:MSP430F5419(100MHz)

GSM Module

Band:850/900/1800/1900MHz

Tally with: GSM phase 2/2+

-Class 4 (2W @ 850/900MHz)

-Class 1 (1W @ 1800/1900MHz)

Max RF Output: 33.0dBm±2dBm

Dynamic Input Range: -15 ~ -102dBm

Receiving delicacy: Class  RBER≤2%(-102dBm)

Frequency Stability: > 2.5ppm

Max Frequency Deviation: ±0.1ppm

RMS Deviation:  ≤5deg

GPS Module

GPS chip set: SiRF Star4

Frequency: L1, 1575.42 MHz

Number of Channel: 20

Reacquisition: 0.1 sec, average

Hot boot: 2 sec., average

Warm boot: 38 sec., average

Cold boot: 44 sec., average

Altitude limit: 18000 m

Velocity limit: 515 m/s

Input I/O

7 I/O input Port

1 port use to check the engine ( ACC check)

1 port use to SOS

1 A/D Input port( Fuel monitoring)

1 Output port ( Car engine control )

3 Extend ports ( Input/Output control by software)

RS232

Two

One is connect to the camera (130M pixel)

Other is extending ports, can connect to LED screen.

Microphone

3.5mm single track

earphone

3.5mm

Current

Not working Current 16mA

working Current:60~150mA

Current of opening infrared of Camera at night  :100~200mA

Charging current: Max<500mA

Battery

Lithium battery :400mA( working time is about 3.5 hours)

Accessories

Device, Connecting cable ,GPS antenna ,GSM antenna, Engine controller, SOS button, Microphone, Camera, LED advertising display(optional)
