- Weifang PALCONN Plastic Technology Co.,LTD
-
Shangluo, Shaanxi, China
- Main products: PEX, PE-RT, PP-R, PB, NFβPP-R, PEX-AL-PEX, PPR-AL-PPR, PE-AL-PE pipe&fittings
Home > Products > PEX pipe & PEX composite pipe > under floor heating PEX-b tube
under floor heating PEX-b tube
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | PALCONN | Place of Origin | China | |
| Model Number | PAL-PEX |
Product Description
PALCONN PEX (cross-linking polyethylene)pipe adopts HDPE as main material, chemical covalent bonds formed in polyethylene molecular chains through cross-linking making molecules forming three dimensional net structure, having good heat & pressure resistance , and other physical and chemical performance.
100% COSTAB raw material
we're CE& ISO passed factory
DIN 4726 sdandard:
| Pressure | Size(mm) | Pressure | Size(mm) |
| dn16*1.8 | dn16*1.8 | ||
| S5PN1.25Mpa | dn20*1.9 | S4PN1.6Mpa | dn20*2.3 |
| dn25*2.3 | dn25*2.8 | ||
| dn32*2.9 | dn32*3.6 |
ASTM F876/877 sdandard:
| Technical information | |||||
| Nominal ID | OD | Wall Thinkness | Avg.ID | Bend Radius | Volume gal/100' |
| 3/8'' pex tubing | 0.5 | 0.07 | 0.35 | 4'' | 0.5 |
| 1/2'' pex tubing | 0.625 | 0.07 | 0.475 | 5'' | 0.921 |
| 5/8'' pex tubing | 0.75 | 0.088 | 0.574 | 6'' | 1.34 |
| 3/4'' pex tubing | 0.875 | 0.097 | 0.681 | 7'' | 1.837 |
| 1'' pex tubing | 1.125 | 0.125 | 0.862 | 19'' | 3.025 |
| 1-1/4'' pex tubing | 1.375 | 1.054 | 11'' | ||
| 1-1/2'' pex tubing | 1.625 | 1.244 | 13'' |
