Commercial Steam Bath Generator 5kw 240v Eletronic 3 phase Wet Steam generator automatic drain

Brand Name	TOLO		Place of Origin	China
Model Number	TOLO-E50

Delivery Time:1-3 workdays
Certification:CE

Commercial Steam Bath Generator 5kw 240v Eletronic 3 phase Wet Steam generator automatic drain

Quick Detail:

Name brand: TOLO Control panel: touch screen digital and optional Type: Wet Steam Sauna Main Material: stainless steel tank and Mirror-polished stainless steel shell Auto function: auto water inlet , auto drain, auto flushing, auto power off Shape: Cuboid Size: 405x150x280mm Usage: steam sauna room Heating: heat elements Power source: Electric Time Setting: 1-60mins Working time: 1~60 minutes or long time Temperature range to control: 95 F degree~131 F degree Temperature range to show on control panel: 43 F degree ~140 F degree Power output: 5.0kw Room volume(cubic meter):4~6 voltage: 220~240V/380~400V phase: 1/3 Current: 22.7A/9.1A Color: stainless steel Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others

TOLO-E?steam generators have middle size to install easily.

They have 304 stainless steel water tanks, 304 stainless steel heating element with high quality Teflon to prevent water scale.

The KSA Elegance touch screen control kit has 6 bottoms to set working stages. Working time 1-60mins can be adjusted or long , the setting temperature of the steam will be in 6-60C degrees and can be adjusted between 35-55C degree (95-131F degree).TOLO-E steam generators feature an advanced electronic control with fault diagnostics having different code to show each operation of the generators. Safety features include boil dry protection, thermal overload safety cut out and pressure relief valve.

Steam Bath Generator 5kw 240v Eletronic 3 phase For Residential / Commercial use

Touch screen control panel with Digital display Control panel used the advanced inducing technology Controls sauna temperature 35 degree to 55 degrees Controls sauna time 1 minute to 60 minutes or long time Intelligent to heat by segment Intelligent to fill water with steam Intelligent to do a self flushing cycle Light can be connected to controller Intelligent to indicate fault with the code To show CH can working for long Automatically shuts down when water level is too low Temperature high limit switch Waterproof grade: IPX5 Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others Auto function: auto water inlet , auto drain, auto flushing, auto power off We will provide some spare parts to our customer as replacement.

Description:

The TOLO-E?steam generator is with new electronic touch screen control kit and new mirror-polished stainless steel 304# steam nozzle. Full body made of stainless steel, durable and luxurious.

1. It is intelligent to heat by 3 groups of heating elements, they alternates on and off to gently maintain the temperature without large fluctuation. This will help the steam fast response after steam generator power on.

From cold all 3 groups operate for maximum power and rapid heating, when the steam room temperature is almost reached, then group 1 stop, when the required temperature is achieved, then group 2 stop. The group 3 alternates on and off to gently maintain the temperature without large fluctuations improving user comfort.

2. TOLO-E?steam generators have an auto drain down with the 8kg power drain valve. At the end of each steaming session the drain valve will open and after a short time the cold water inlet valve will open to give a period of continuous flushing and draining. Flushing and draining the boiler reduces the build up of damaging limescale, cooling the elements before the final drainage helps prolong their useful life.

3. TOLO-E?is with new touch screen electronic control kit. The elegance series control kit is easy to operate. Shine model style with white LED lights. It is intelligent to protect when overheating, to protect when shortage of water and when over pressure of inside of water tank.

4. Imagine being able to shut the door on the world for a few minutes every day. Billows of warm, gentle steam wash over you, relaxing muscles, opening pores, inducing a skin-healthy perspiration. The origins of the steam bath come from the Roman bath, which began during the height of the Roman Empire.

Applications:

For 4~6m3 residential and commercial steam baths

A daily steam bath is a remarkable way to indulge yourself. It causes the?perspiration that is the single healthiest thing you can do for your skin. Stress and?negati
