Micro Vickers Hardness Tester HVS-1000 with Easy operating system

Digital Micro Vickers Hardness Tester HVS-1000 with Easy operating system

The micro-Vickers hardness tester HVS-1000 is especially well suited for high precision hardness testing of small and/or thin specimens such as sheet, foil, coatings, ceramic products, and hardened layers. To ensure a satisfactory indentation, the HVS-1000 features automatic loading and unloading operations, a very precise loading mechanism and a robust lever system. The micro-computer controlled system ensures an absolutely precise hardness measurement with adjustable dwell time.

Details:

Applications:

? Easy operating system
? Fully automatic load control
? Hardness computation and statistics
? Integral priner
? Two optical paths
? XY stage with minimum reading of 0.01mm

Specifications:

? Test force (N): 0.098N (10gf), 0.246N (25gf), 0.490N (50gf), 0.980N (100gf), 1.961N (200gf),
??2.941N (300gf), 4.903N (500gf), 9.806N (1000gf)
? Test force selection: Dial
? Loading accuarcy: 1%
? Loading control: Fully automatic (loading/dwell/unloading)
? Loading duration: 5 to 60 sec(5 sec increments)
? Microscope
? Objectives: 10x, 40x
? Total magnification: 100x (observation), 400x (measurement)
? Measuring range: 300x300um
? Resolution: 0.025um
? XY stage
? Dimensions: 100x100mm
? Travel range: 25x25mm
? Resolution: 0.01mm (micrometers)

Specimen:

? Maximum height: 65mm (2.55\")
? Maximum depth: 85mm (3.35\") from the center of indenter
? Optical path: 2-way switchable (microscope/photographic device)
? Display
? Hardness value: 5-digit
? Diagonal length: 4-digit (D1, D2)
? Output: Integral printer/including statistics program
? Power supply: 220v AC (10%) 50/60Hz
? Power consumption: 20VA
? Dimensions: 290x405x480mm
? Mass: 25kg
