Customize Double Layer Roll Forming Machine with 10 - 12Mpa Hydraulic Pressure
USD $20000 - $35000/
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Double Layer Roll Forming Machine with Speed 15-18m / min for Corrugated Roof
-
Cable Tray Double Layer Roll Forming Machine with Cr12mov Blade / 20 Groups Rollers
-
5.5kw Hydraulic Station Power Steel Sheet Forming Machine for IBR Roof in One Line
-
380V Double Layer Roll Forming Machine with Alternating Current Frequency Conversion
-
60Hz 3 Phase Double Layer Roll Forming Machine for Roof Panels
-
5.5kw Glazed Steel Tile Forming Machine for Steel Structure Workshop
Product Details
| Brand Name | DB | Place of Origin | China | |
| Model Number | According to profile |
Product Description
Certification:CE & SGS
Customize Double Layer Roll Forming Machine with 10 - 12Mpa Hydraulic Pressure
Application:
Double Layer Roll Forming Machine can separate produce corrugated roof and IBR roof in one line or similar two profiles.
The products are widely used in building the steel-structure large-scale warehouse, plants, supermarkets, shopping malls, trade markets, stadiums, holiday villages, sanatoriums, hotels, villas, residences, and different kinds of greenhouses.
Technical Parameters:
| Material Spec: | Colored Steel Sheet; Galvanized Steel Sheet |
| Thickness of Coil Sheet: | 0.3-0.8mm |
| Main Motor Power: | 5.5KW |
| Forming Speed: | 15-18M/MIN |
| Hydraulic Station Power: | 5.5 KW |
| Quantity of Stands: | 17 Stands |
| Total Weight: | About 80000KGS |
| Controlling System: | PLC |
| Hydraulic Pressure: | 10-12Mpa |
| Index Error of Length: | 10M ± 2mm |
| Voltage: | 380V 3 Phase 60Hz or At Buyers Requirement |
Main component:
Advantage:
available for two profiles roof panel shared one frame, save the cost.
1) Used to produce different roof panels and wall panels
2) Produced panels have such advantages as below:
a) Fine profile
b) Attractive color
c) Agile connecting
d) Slightly curved
3) dual-level roll forming machine
4) We can design and manufacture different type of it to hit your particular profiles
Drawing for refer:
Machine for refer:
