Home > Products > COFDM Receiver > Digital Portable High Definition wireless Digital AV Wireless Video Receiver
Digital Portable High Definition wireless Digital AV Wireless Video Receiver
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
H.264 Video Compression Wireless HD SDI Transmitter for Commending Center
-
High Speed HD Wireless Transmitter 1080P , Standard COFDM Modulation Technology
-
C1000 Handheld Patrol COFDM 1080P Full HD AV Digital Video Receiver
-
1 Watt Standard Definition Wireless Video TDD Transmitter for UAV
-
Time Division Duplexing TDD SD Transmitter for Telemetry / Geological Monitoring
-
T321S-500 TDD SD Video Wireless Transmitter 1W , Strong Diffraction
Product Details
| Brand Name | LinkAV | Place of Origin | China | |
| Model Number | C1000 |
Product Description
Certification:CE Applicable
C1000 Handheld Portable COFDM Receiver HD wireless Digital AV?
Product Features:
The LinkAV C1000 handheld COFDM receiver is a fully portable addition to the Rinicom range of digital video products. It contains an integrated digital receiver for use with C1000 transmitter units.
Compact, battery powered and light weight, the C1000 HHR is designed for customers who require a discrete and completely portable surveillance solution.
The intelligent design of the C1000 HHR reduces setup time and ensures reliable reception of video, audio and data in non line of sight conditions.
The C1000 HHR is suitable for line of sight and non line of sight transmission. Further range may be achieved by selecting reception mode, booster amplifiers and antenna type. The unit can be combined with a variety of antennas and other RF accessories in order to achieve greater range.
Video is transmitted using an C1000 COFDM transmitter. See the RiniLink C1000 Tx product brief for configuration options.
Technical Parameters:
|
Item |
Description |
|
Modulation Type |
COFDM |
|
Working Frequency |
46-860MHz; per 0.5M adjustable |
|
RF Bandwidth |
2/3/4/5/6/7/8MHz(optional) |
|
Sensitivity |
-106dBm |
|
Video Output |
HDMI display,External?Display?Screen:?AV?Output |
|
Video Compression |
MPEG-2, H.264 |
|
Audio Output |
3.5 mm headsets |
|
Forward Error Correction |
1/2,2/3,3/4,5/6,7/8 |
|
Parameter Control Method |
Adjustable Digital LED Control Panel |
|
USB |
External Memory: U Flash Disk |
|
Encryption Method |
128 - bit AES (can set user’s password) |
|
Antenna Interface |
N Female Head*2 |
|
Display Screen Size |
10.1 Inches |
|
Working Voltage |
DC12V |
|
Working Current |
1Ah to 1.5Ah |
|
Working Temperature |
-10~70℃ |
|
Dimensions |
300*200*30(mm) |
|
Weight |
2(Kg) |
? ? ? ? ? ? ? ? ? ? ? ? ?Zhongchuang Tech?is specialized in COFDM, TDD and 3G/4G wireless video transmission products for over 9 years, including video wireless transmitter, video wireless transmitter and receiver, quality video wireless transmitter, products are applied widely among Public Security Bureaus, Forest Fire Prevention Departments, Maritime Bureaus, Oil Field, Construction Sites, Tunnels,UAV, Automobiles and so on.
