Super Bright CREE XM-L2 U2 LED Diving Canister Light With Type III Hard Anodizing

Brand Name	DLN		Place of Origin	China
Model Number	DH160

Certification:CE, RoHS

DH160 6500 Lumens Multi Function Technical Dive Lights with Red and UV Light

PRODUCT SPECIFICATIONS:

Model	DH160 Canister Diving Video Light?
Bulb	White CREE XM-L2 U2 LED *12 (max 6500 Lumens); CREE XP-E N3*4 (wavelength 620nm, max 400 Lumens)
Modes	High>Medium> Low>Red> off
Runtime	High (1.5h); Medium? (3.0h); Low (5.0h); Red (8.0h)
Color temperature	5000K (white light)
Reflector	No hotspot design, no reflector
Lens	5mm Polycarbonate Board
Body material	Durable aircraft-grade aluminum
Angle of light beam	120°
Surface treatment	Premium Type III hard-anodizing
Color	Black
Battery	Rechargeable Li- ion battery pack (26650 battery*8)
Battery Indicator	100%-50%: Green; 50%-30%: Yellow; 30%-10%: Red; Below 10%: Red Flashing; Below 5%: switch off
Charging	Can be charged directly on the light, with battery over-discharging protection, polarity reversing protection
Fully charging time	8-10h
?	With gas release valves
Operation voltage	12V to 18V
Waterproof	200 meters underwater
Dimensions	244.5mm (canister length)* 78.2mm (dia. Of canister) * 56.5mm (dia. Of light head)
Weight	2230 grams (with battery pack)
Underwater Weight	1100 grams (with battery pack)
Impact resistance	1.5M

BATTERY CHARGING

Plug the charger in the wall power socket, the indicator light is green in the free-load status. Plug the port of the charger in the ports on the light. (the positive and negative polar doesn’t matter, both ways work.) The indicator light is red if the battery is not fully charged; it will turn green after fully charged. Take out the charger, put the cover on the canister and use the light.

ON/OFF

Push the switch to turn it ON.

MODES CHANGING

Successive push the switch ON-OFF within two seconds to cycle through High, Low, strobe, OFF.

SCUBA DIVING APPLICATION

Check closely for cuts, scratches, or an otherwise damaged O-ring or mating lens surface as this can cause the light to flood under pressure. Remove any salt deposits, sand, dirt, or other foreign matter from the O-ring sealing surfaces.

KEEP THE THREADS, O-RING GROOVE LUBRICATED WITH SILICONE GREASE.

CAUTION

If the light is not to be used for some time, remove the batteries to prevent possible leakage or corrosion. Please put the switch on the canister to the position of “OFF” during transportation to prevent it from misoperation.

If the switch gets stuck, please put some washing-up liquid in the slot of the switch and push the switch back and forward several times till it move smoothly again, then clean the light in the fresh water.

WARRANTY RETURN POLICY

Please contact your local distributor or retailer for information on how to handle your warranty items.

REPLACEMENT PARTS

CAT#???????????? DESCRIPTION

WH1608???????? O-ring

WH1609???????? Lens
