Stage background 15.6mm Outdoor Full Color LED Signs Waterproof Protection
- 0 per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
SMD 2724 RGB Super Thin Indoor Advertising LED Display With Seamless Splicing
-
Epistar P20mm Indoor Full Color LED Display LED Billboard Display 50Hz / 60Hz
-
Flexible P10 Carbon Fiber Indoor Full Color LED Display wind resistant LED wall
-
P15 Large RGB Waterproof Indoor Full Color LED Display Long Lifetime
-
P15 Electronic Animation Curved LED Screen LED Moving Message Display
-
P 10 Animation Photo Curved LED Screen Outdoor Advertising LED Display
Product Details
| Brand Name | GLUX | Place of Origin | China | |
| Model Number | ODsn15C |
Product Description
Certification:CE ROHS TUV
Stage background 15.6mm Outdoor Full Color LED Signs Waterproof Protection
Quick Detail:
1.Name:ODsn15C
2.Pixel Pitch:15.6mm
3.High brightness, 5000 nits
4.Long life span more than 50000H
5.Super thin?Carbon fiber cabinet
6.Waterproof IP65
7.Max vertical hanging 1400kg
Description:
1.SMD 3-in1 outdoor LED display
2.Carbon fiber materials for super light and thin structure
3.Angled edge struture for up to 90 degree curved assembly
4.Specific and targeted installation means fast setup and fast dismantling
5.Advanced pixel correction for the sharpest image quality
6.LCD info display: indicating product performance
Applicantion:
Sports,advertising, entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc?
Specifications:
|
Glux?LED?Display??ODsn?Series |
ODsn15C |
|
Pixel?Pitch(mm) |
15.6 |
|
Pixel?Density(dots/m2) |
4096 |
|
Brightness(cd/m2) |
5000 |
|
Color?Temperature(after?calibration)K |
6500 |
|
Module?Size(W*H*D)(mm) |
500*500*56 |
|
Weight(kg/Panel) |
5 |
|
Weight(kg/m2) |
20 |
|
LED?Type |
3535White |
|
LED?Chip |
Epistar |
|
Horizontal/Vertical?Viewing?Angle(o) |
H160o/V160o |
|
Recommended?Viewing?Distance(m) |
≥8 |
|
Contrast |
1200:1 |
|
Refresh?Rate(Hz) |
8000 |
|
Grey?Scale(bit) |
R/G/B?16 |
|
Frame?Rate(Hz) |
50/60 |
|
Life?Time(H) |
≥50000 |
|
Protection |
IP65 |
|
Power?Supply |
Sigular?Power?Supply |
| Working Voltage(V) | AC 110~240 |
|
Max?Power?Consumption(W/M2) |
600 |
|
Avr?Power?Consumption?(W/M2) |
200 |
|
Working?Temperature |
-25-40℃ |
|
Working?Humidity |
10%-95% |
|
Driving?Mode |
Static |
|
Cabinet?Material |
Carbon?Fiber |
|
Video Signal Input Interface |
DVI/HDMI/HDSDI |
|
Max?Hanging(Vertical) |
1400kg |
Feature Advantage &?Competitive?Advantage:
1.Energy?efficient
2.ODU?Connector?(made?in?Germany)
3.Usage?Status?Display
4.Protective?Buffer
5.International?Protecting?rate?IP65
6.Test?Button
7.45?Degree?Curved?Frame
8.Carbon??ber?construction
9.Ultra-thin?design?&?lightweigh?Only?20kg/sqm
10.Modular?design?for?convenient?maintenance
