Double Girder Overhead Crane Industrial Electric Hoist For Indoor Medium Duty 50T

Double?Girder?Overhead?Crane?With?Electric?Wire?Rope?Hoist?For?Repair?Workshop?/?Warehouse?For?Indoor?/?

Outdoor

Detailed?Product?Description

Description:

Double?girder?overhead?industrial?crane?is?characterized?by?strong?bearing,?big?span,?and?overall?stability?with?

various?models,?but?their?quality?is?better?compared?with?single?girder?gantry?crane?with?the?same?capacity.?They

?are?available?with?load?capacities?up?to?50T?and?with?spans?up?to?35?m.?Articulated?end?carriage?joints?ensure?

positive?contact?of?all?four?wheels?with?the?track.?The?range?of?fixing?arrangements?allows?the?appropriate?

integration?of?double?girder?travelling?cranes?into?new?buildings?as?well?as?into?existing?buildings.?Just?as?with

?all?other?types?of?double?girder?travelling?cranes,?the?profiles?of?the?main?girder?are?optimally?produced?using?

computers?so?that?maximum?performance?with?a?minimum?of?dead-weight?can?be?achieved.?An?advantage?that

?has?financial?benefits.

?
Double?girder?overhead?crane?with?hoist?are?widely?used?in?the?following?applications:

1.???????Light?duty?cranes?for?repair?shops,?light?assembly?operations,?service?buildings,?light?warehouses,?

where?service?requirements?are?infrequent.

2.???????Medium?duty?cranes?for?machine?shops?and?general?industrial?use?both?indoor?and?outdoor?application.

3.???????Extra?heavy?duty?cranes?for?steel?mills?and?other?heavy?machine?shops,?steel?warehouses,?heavy?

fabrication?shops,?paper?mills?etc.?with?magnet?and?bucket?operation?for?scrap?yards,?fertilizer?plants?&?

induction?furnace.

4.???????Extra?heavy?duty?cranes?for?steel?mills?and?other?heavy?engineering?purposes.?Cranes?designed?for?

hot?metal?application?on?request.

Design?features?include:

DESIGN:
Compact?dimensions,?low?weight,?easy?to?operate?and?easy?to?maintain,?modular?design?with?direct?fits?

between?components

Structure:?
Bridge?Girder,?End?carriages,?Crab?Frame?manufactured?from?box?plate?design?/?Rolled?Sections.?If?required?

100%?radiography?of?all?butt?welding?joints?of?bridge?and?end?carriages?can?be?provided.

MOTORS:
Nante?Crane?uses?sturdy?cylindrical/?conical?rotor?pole-changing?motors?with?elegant?continuous?cast?

aluminum?sections,?integrated?safety?brakes?insulation?class?F,?IP54?protection.

Variable?Frequency?Drives?&?Remote?Controls:
We?also?offer?Variable?Frequency?Drive?in?hoisting,?cross?travel,?long?travel?for?stepless?speed?control?as?an

?optional?feature.?We?also?provide?radio?remote?control?cranes?for?application?in?inaccessible?and?hazardous?

areas.
Brakes?
Failsafe?magnetic?or?hydraulic?brakes?of?150%?torque?or?more?are?fitted?on?shaft?extensions.?For?heavy?duty?

cranes?a?second?brake?can?be?mounted?to?ensure?failsafe?operation.
Controls?
Pendant?control?from?floor,?master?control?switches,?master?controllers?in?the?driver\'s?cabin?can?be?provided.?

Radio?remote?control?can?be?provided?on?request.

ELECTRICAL?PANEL:
Modular?design,?covering?a?very?wide?operating?range.?The?systems?are?designed?for?ease?of?installation?and?

maintenance?and?reliable?operation,?with?fuseless?circuitry,?ducted?wiring?and?non-screwed?terminals.?Each?

drive?group?is?equipped?with?a?motor?overload?protection?device?to?provide?effective?protection?against?

inadmissible?overloading.

PAINTING:
Every?component?&?part?is?thoroughly?scrubbed?&?painted?with?two?coats?of?primer?before?assembly?&?two?

coats?of?synthetic?enamel?after?testing.

LIMIT?SWITCHES:
To?prevent?over?hoisting?&?over?lowering?of?hook.
