R4M Continuous Casting Machine 1 Strand Carbon Water Cooling Continuous Casting Machine
- T/T L/C D/P D/A
- 7 days
You May Like
-
Industrial Metal CCM Continuous Casting Equipment , R8m & 8 Strands
-
R4M 1S Billet CCM Continuous Casting Machine , Dummy Bar
-
10T CCM Billet Casting Machine With 1 Strand and Ladle Car / Ladle Turret
-
R4M 1S Metering nozzle Continuous Casting Machine With Simple Cooling Bed
-
Secondary Cooling Billet Casting Machine , R6M 1 Strand ISO Slab Caster
-
Semi-portal CCM Continuous Casting Machine 1 / 2 Strands
Product Details
| Brand Name | HAIJUN | Place of Origin | China | |
| Model Number | R4M 1strand |
Product Description
R4M Continuous Casting Machine 1?Strand?Carbon?Water?Cooling?Continuous?Casting?Machine
ntinuous caster steel
2,kinds of arc radius?
3,kinds of billet type?
4,kinds of strand?
5,More options
We can produce high quality continuous casting machines from 1 to 8 strands with the lowest equipment manufacturing cost.We can design, manufacture the up-to-date billet continuous casting machine in accordance with the user\'s steelmaking capacity, billet size, steel grades and the user\'s field conditions.
1.?Basic?standby?technical?parameters:
|
Steel?billet?casting?machine?radius |
4m |
|
Strand?quantity |
1?strand |
|
Ladle?support?type? |
Dumping?ladle,Ladle?mounts,Ladle?car |
|
Tundish?carriage |
Semi-portal,?cross?sliding?function |
|
Casting?method |
Metering?nozzle,?open?casting |
|
Secondary?cooling |
Water?cooling?,?1?adjusting?circuit |
|
Withdrawal?straightening?machine |
Totally?5?roller,?progressive?straightening |
|
Roll?table |
Chain?group?centralized?drive |
|
Dummy?bar |
Rigid,?with?self-adapting?dummy?bar?head |
|
Billet?cutting |
Manual?cutting |
|
Billet?conveying |
Group?centralized?live?roller?table |
|
Cooling?bank?type |
Simple?cooling?bed |
2.??Technical?process?description?and?capacity?of?steel?billet?CCM
Induction?furnace:
|
Nominal?capacity |
5T |
|
Tap-to-tap?cycle?? |
45min |
|
Furnace?quantity?? |
3set |
Production?capacity??
|
Working?days |
330?days/year |
|
Average?number?of?daily?furnace |
24/day |
|
Production?capacity |
80000t/year |
3.??Casting?speed,?productivity?and?strand?quantity
????R4m?radius?casting?machine?can?cast?steel?groups?of?different?specifications,?
??? the?maximum?casting?speed is?as?follows:
|
Casting?sectional?area(mm) |
80×80 |
100×100 |
120×120 |
|
Casting?speed(m/min) |
3.0 |
2.8 |
2.6 |
|
NO. |
Billet size |
Casting?speed |
hourly?output (tons) |
Daily?output 24hour (tons)???? |
Annual?output(330days)? (tons) |
|
1 |
80×80 |
3.0m/min |
7.42 |
178? |
58,766 |
|
2 |
100×100 |
2.8m/min |
10.81 |
259.? |
85615 |
|
3 |
120×120 |
2.6m/min |
15.69 |
377 |
124,266 |
The?calculation?results?is?the?ideal?state?of?the?production,?please?according?to?own?actual?situation?of?
?adjustment.
|
Steel?grade |
Casting?grade(m/min |
Effective?deformation?rate(ε) |
Allowable?deformation? rate(εmax) |
