CCM Continuous Casting Machine Automatic Electric R8M 8S CCM

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HAIJUN		Place of Origin	China
Model Number	R8M 8strands

Delivery Time:6 months

CCM Continuous Casting Machine Automatic Electric R8M 8S CCM

Rigid, with self-adapting dummy bar head

radius: R8M

Strand number : 8 strands

with ISO certification

advanced design

Description:

1. Basic standby technical parameters:

Steel billet casting machine radius	8m
Strand quantity	8 strands
Ladle support type	Ladle turret
Ladle turret	Straight arm type
Tundish car	High-low track drive, cross sliding function
Casting method	Metering nozzle, open casting,casting powder
Secondary cooling	Gas and water cooling ,2 adjusting circuit per strand
Withdrawal straightening machine	Totally 5 roller, progressive straightening
Roll table	Chain group centralized drive
Dummy bar	Rigid, with self-adapting dummy bar head
Billet cutting	Auto flame cutting machine
Billet conveying	Group centralized live roller table
Cooling bank type	Sliding way,shift steel machine

2. ?Technical process description and capacity of steel billet CCM

Induction furnace:

Production capacity?

Working days	330 days/year
Average number of daily furnace	24/day
Production capacity	1000,000～1200,000t/year

3. ?Casting speed, productivity and strand quantity

??? R8m radius casting machine can cast steel groups of different specifications, the maximum casting speed is as follows:

Casting sectional area(mm)	?180x180	200×200	220×220
Casting speed(m/min)	1.6	1.8	2.0

??? The calculation results is the
