Flexible 7x7 316 Stainless Steel Wire Rope 2.5mm For Industrial , AISI / BS / ASTM
- T/T L/C D/P D/A
- 7 days
You May Like
-
Decorative 3MM 304 Stainless Steel Wire Rope 19x7 With Tensile Strength
-
20mm Stainless steel Wire Rope 7x19 With EN12385-4 / AISI / BS / ASTM / JIS
-
Industrial 30mm 316 Stainless Steel Wire Rope 6x37 With DIN / AISI / ASTM , 1870MPA
-
5mm Bright 316 Stainless Steel Wire Rope 1960MPA , 6x19+I WRC AISI / BS / ASTM
-
ASTM 316 Nylon Coated Stainless Steel Wire Rope 1x37 and Diameter 25mm
-
Polished 14mm 1x7 Stainless Steel Wire Rope AISI 304 / 304L , IWR Core
Product Details
Brand Name | TianLi | Place of Origin | China | |
Model Number | 316 |
Product Description
Certification:ISO
Flexible 7x7 316 Stainless Steel Wire Rope 2.5mm For Industrial , AISI / BS / ASTM
Quick Detail:
Grade: 316 stainless steel wire rope
Structure: 7*7S+Fc/7*7S+IWR/7*7W+ISR
1, Diameter: 1- 50mm
2, Standard: DIN, GB, EN12385-4, AISI, BS, ASTM, JIS etc
3, T/S: 1570MPA, 1670MPA, 1770MPA, 1870MPA, 1960MPA
Description:
Stainless steel wire rope:
1. Standard: DIN, GB, EN12385-4, AISI, BS, ASTM, JIS etc
2. Diameter: from 0.5 mm to 20mm
3. T/S: 1570MPA, 1670MPA, 1770MPA, 1870MPA, 1960MPA
4. Packing: Wooden box and bagging, or according to customers\' request.
5. Delivery date: 30days after the order confirmation.
6. We have ISO and SGS certificates
Stainless steel wire rope Mainly used for decoration, chemical metallurgy, petroleum machinery, port machinery, nuclear industry, the coal, metallurgy, chemicals, shipbuilding, bridges, electricity, rubber, military, tourism, water, light industry, aviation and aerospace industry.
Applications:
With bright surface, slight magnetism and no cracks on forming, is widely used in crane, bicycle fittings, kitchen and sanitation tools, goods shelf, pet cages, gill racks, decorative handles and baskets, food and medical machinery accesses, etc.
Specifications:
Diameter (mm) |
Min.Breaking Load????????????????????????????????????? (KN) |
Approx.Weight Kg/100m |
0.36 |
0.083 |
0.0531 |
0.45 |
0.140 |
0.0830 |
0.5 |
0.185 |
0.1025 |
0.6 |
0.215 |
0.1476 |
0.8 |
0.460 |
0.2624 |
1.0 |
0.637 |
0.0405 |
1.2 |
0.98 |
0.585 |
1.5 |
1.48 |
0.911 |
1.8 |
2.15 |
1.31 |
2.0 |
2.94 |
1.62 |
2.5 |
4.4 |
2.53 |
3.0 |
5.71 |
3.65 |
4.0 |
10.2 |
6.4 |
5 |
15.9 |
10 |
6 |
22.9 |
14.4 |
8 |
42.5 |
25.6 |
10 |
56.3 |
40 |
12 |
81.1 |
57.6 |
14 |
110 |
78.4 |
16 |
144 |
102.4 |
18 |
183 |
129.6 |
20 |
255 |
160 |
Competitive Advantage:
1,It features ultra-high corrosion resistance,
2,surface quality, high brightness, strong corrosion resistance,
3,tensile strength and fatigue strength.
4,In particular, 316, and high corrosion resistance,
5,316 stainless steel wire rope widest range of uses,
6,mainly for the food industry and surgical equipment.
