High Corrosion Resistance Galvanized Steel Coil For Construction / Base Metal

Brand Name	Sincere		Place of Origin	China

Delivery Time:10-30 days
Certification:CE & SGS
High Corrosion Resistance Galvanized Steel Coil For Construction / Base Metal Quick Details Standard:ASTM,BS,DIN,JIS, EN Grade:SGCC Thickness:0.15-4.0mm Place of Origin:China (Mainland) Brand Name: Sincere Model Number:SGCC Type:Steel Coil Technique:Cold Rolled Surface Treatment:Galvanized Application:Construction & Base Metal Width:600-1500mm Length:Steel Coil Description:Galvanized Steel Coil Base Metal:SPCC Available Dipped Layers:50-275g/m2 Inner Diameter:508-610mm Available Surface Treatment:Passivating & Oiling & AFP & Filming HS Code:72104900 Approved Certificate:CE & SGS Specifications

Galvanized Steel Coil
1.ISO9001 approved
2.High adhesivenees and preciseness
3.Excellent mechanical property
?

High Corrosion Resistance Galvanized Steel Coil

Brief Introduction

Galvanized Steel Coil gets coated in layers of zinc because rust won\'t attack this protective metal. The most external layer is all zinc, but successive layers are a mixture of zinc and iron, with an interior of pure steel. These multiple layers are responsible for the amazing property of the metal to withstand corrosion-inducing circumstances. Zinc also protects the steel by acting as a \"sacrificial layer.\" If rust does take hold on the surface of Galvanized Steel Coil, the zinc will get corroded first. This allows the zinc that is spread over the breach or scratch to prevent rust from reaching the steel. For countless outdoor, marine, or industrial applications, Galvanized Steel Coil is an essential fabrication component.

The Protection Principle

1. Anodic reaction: Zn-2e=Zn2+

(The alloy coating loses electron, sacrificing itself in dissolution.)

2. Cathodic reaction: Fe2++2e=Fe

(Fe gains electron reaction, being protected)

Specification

1. Thickness: 0.15-4.0mm

2. Width: 600-1500mm

3. Inner Diameter: 508mm

4. Weight of Steel Coil: 3-18MT

5. Coating Type: Pure Zinc

6. Available Dipped Layer: 50-275g/m2

7. Surface Finish Structure: Zero Spangle & Finishing Small Spangle & Regular Spangle

8. Available Surface Treatment: Passivating & Oiling & AFP & Filming

Mechanical Properties

Grades	Mechanical Property	Coating Adhesion
Yield StrengthMPa	Tensile StrengthMPa	Elongation% ≥	Bending Center Diameter at Following Coating Weight (g/m2) (a=Plate Thickness)
La=80mm b=20(mm)
At Following nominal Thickness ( mm)
≤0.7	>0.7	≤140/140	>140/140-175/175	>175/175
SGCC SGHC	140-350	270-500	20	22	0a	1a	2a
SGCD1	140-300	270-420	24	26	0a	1a	2a
SGCD2 SGCD3	140-260	270-380	28	30	0a	1a	2a

Application

1. Architecture Roofs and outside walls of civilian and industrial buildings, garage doors, fencings and window blinds

2. Appliances Industry Outer clad sheets for washing machine, refrigerator, television, air conditioner and ventilation system, explosion-proof strip, solar water heater and appliance parts

3. Auto Industry Muffler, heat shields of exhaust pipe and catalytic converter, auto parts & accessories under the frame, signboard in highway

4. Industrial Instruments Electric control cabinet, industrial refrigeration equipment, automatic vending machine

Superiority

1. Good Resistance to Corrosion

2. Qualified Proc
