PE adhensive dispenser Syringe Adapter Assembly with controller

adhensive plastic dispensing syringe adapter/dispenser barrel adapter

Specifications:

Barrel Adapter Assembly are the connecting link between dispensers/controllers and Syringe barrels. They provide a safe connection for accident proof dispensing and made available with 1m or 2m of PE pipe. PE pipe outer diameter is 4mm/6mm. The assembly consists of the receiver head with fitted Viton® o-ring, PE pipe and male quick connector.detail offer as customer demand.

Performance of Barrel adapter assembly:

1. It connects the barrel with controller.

2. There is one model for each barrel size. One-piece, the molded adapter provides Safe attachment of barrel reservoir.

3. Assembly includes 5/32 OD flexible polyurethane tubing, Buna N O-ring and quick-connect.

4. For cyanoacrylate dispensing, specify adapter assembly with in-line filter trap.

5. Size: syringe with air hose 3cc/5cc/10cc/30cc/55cc

6. Metal-syringe adapter PP-syringe adapter Make up of PE pipe \"O\" seal Quickly connector Safety buckle

Size available:3cc,5cc,10cc,30cc,55cc

Sales Points/Focus

1. The connecting link between pneumatic dispenser and syringe barrel.?????????????????????????????????????????????????????????????????????????????

2. High density lightweight clear flexible tubing with male quick connect one end - bayonet push and twist head the otherend.?????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????

3.Comes supplied as standard with EPR rubber o-ring.? Safe to use up to 100 psi.? Use Viton o-rings for aggressive solvent based adhesive that can attack standard EPR
