ASTM A106 Round Seamless Hydraulic Cylinder Pipe , Precision Annealed Steel Tubes
- T/T L/C D/P D/A
- 7 days
You May Like
-
ASTM A519 SAE1026 25Mn Hydraulic Cylinder Pipe Cold-Drawn Tube With Thick Wall
-
Cold Drawing Round Hydraulic Cylinder Pipe / E355 DIN2391 ST52 Precision Seamless Steel Tube
-
ASTM A519 Varnish Hydraulic Cylinder Piping / Cold Drawn Precision Steel Tubes
-
DIN 2391 ST35 ST45 Thick Wall Hydraulic Cylinder Pipe , Precision Honed Tube With ISO
-
Annealed Round DIN 2391 Hydraulic Cylinder Tube / High Precision Cold Drawing Steel Pipe
-
Tempered BK EN 10305-1 E355 Hydraulic Cylinder Pipe With Round Shape / Honed Tube
Product Details
| Brand Name | JIANGSU HUACHENG | Place of Origin | China | |
| Model Number | HC |
Product Description
Certification:ISO9001 14001 BV TUV PED DNV etc
ASTM A106 Round Seamless Hydraulic Cylinder Pipe , Precision Annealed Steel Tubes
Quick Detail:
Standards: ASTM A106 Grade B
Material Grade: A519 SAE1026 / A519 SAE1518 / 16Mn / 25Mn / 20# / 45# / 27SiMn / ST45 / ST52 / E355
Size(mm):
ID :45mm – 500mm
WT:3mm – 50mm
Description:
Standards: ASTM A106 Grade B (20#)
(GB/T8713 GB/T3639 DIN2391 EN10305 ASTM A519)
Grade: ASTM A106 Grade B (20#)
Inside Dimensions: 45mm ~ 500mm
Wall Thickness: 3mm ~ 50mm
Length: max 24000mm
Application: Hydraulic Cylinder
Packing:?Beveled/black painting/ plastic caps/ in bundles/ steel strips/ wooden protection
Inspection and Test:?Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test),Surface and Dimension Test,Nodestructive Test, Hydrostatic Test.
Surface treatment:Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting.
Mark:?As per customers’ requested.
Delivery Condition:Annealed, Normalized, Normalized and Tempered.
Processing Range And Precision:
|
Cold Drawn Tubes: ID:45mm-630mm Length:14,000mm Straightness:0.3-1.0 Precision:H8-H10 Roughness:Ra0.8-Ra1.6 |
Honing Tubes: ID:25mm-500mm Length:10,000mm Straightness:0.3 Precision:H7-H8 Roughness:Ra0.2-Ra0.8 |
ID Tolerance of Precision Honed Tubes:
|
SIZE of I.D |
I.D.Tolerance |
Tolerance of wall thickness |
||
|
H8 |
H9 |
H10 |
||
|
30 |
+0.0330 |
+0.0520 |
+0.0840 |
<120mm(O.D)???????????????? ±5% ≥120mm(D.D) to 210mm? ±7.5% >210mm???????????????????????? ±10% |
|
>30-50 |
+0.0390 |
+0.0620 |
+0.1000 |
|
|
>50-80 |
+0.0460 |
+0.0740 |
+0.1200 |
|
|
>80-120 |
+0.0540 |
+0.0870 |
+0.1400 |
|
|
>120-180 |
+0.0630 |
+0.1000 |
+0.1600 |
|
|
>180-250 |
+0.0720 |
+0.1150 |
+0.185 |
|
|
>250-315 |
+0.0810 |
+0.1300 |
+0.2100 |
|
|
>315-400 |
+0.0890 |
+0.1400 |
+0.2300 |
Mechanical Propety:
Material:?20# 45#,16Mn St45, St52, 25Mn,27SiMn, SAE1026.SAE1518 etc.
STANDARD: GB/T8713 GB/T3639 DIN2391 EN10305 ASTM A519
|
Delivery condition |
cold finished(hard)(BK) |
cold drawn and stress relieved(BK+S) |
|||
|
STEEL GRADE |
Rm? MPa |
Elongation (%) |
Rm? MPa |
ReH? MPa |
Elongation (%) |
|
ASTM A106 Gr.B |
≥550 |
≥ 8 |
≥ 52 |
