Home > Products > Aluminium Construction Profiles > 6463 Aluminium Construction Profiles With Electrophoresis Champange
6463 Aluminium Construction Profiles With Electrophoresis Champange
Negotiable
/ Square Meter
1 Square Meter(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
6063 Aluminium Construction Profiles With Champange Anodizing
-
6063 Aluminium Construction Profiles With Champange Anodizing / Brush
-
High Intensity Aluminium Construction Profiles With Bronze Anodizing
-
6063 / 6060 T5 Aluminium Construction Profiles With Bronze Anodizing
-
Bronze Anodized Industrial ArchitecturalAluminium Profiles 6063 T5
-
Extruded Aluminum Shapes 6063 T5 , Bronze Anodised Aluminum Structural Shapes
Product Details
| Brand Name | DeYuan | Place of Origin | China | |
Product Description
Certification:ISO9001:2004, SGS
6463 Aluminium Construction Profiles With electrophoresis champange
Description:
| Material | 6063 6060 6463 T5 T6 T66 |
| Surface | Mill Finished, Anodizing, Electrophoresis, Powder Coating ,Polishing, Wooden grain, Sand Blasting |
| Color | Clear Satin, Bronze, Black, Golden, Silver, other colors for Powder Coating |
| MOQ | 1ton. Usually 12 tons for a 20 feet container; 24 tons for a 40 feet container. |
| Length |
For Anodizing and Electrophoresis: Maximum 6.8 Meters For Powder Coating : Maximum 12 Meters |
| Packing | 1) EPE, waterproof paper wrapped in small bundles. 2) paper interleave each piece and packing in wooden box and finally on Steel Rack to pull into container |
| Sample delivery | Two weeks (one week for mould +one week making sample) |
| Sample design | It is better we can get your drawing or sample, we mainly make according to your design, and we can keep confidential for your design. |
| Maximum extruder machine | 3500 tons; Minimum extruder machine: 500 tons |
Primary Technical Data
1) Chemical composition
| Alloy | Si | Mg | Fe | Cu | Mn | Zn | Cr | Ti |
| 6063 | 0.2~0.6 | 0.45~0.90 | <0.35 | <0.10 | <0.10 | <0.10 | <0.10 | <0.10 |
| 6060 | 0.3~0.6 | 0.35~0.60 | 0.1~0.3 | ~ | <0.10 | <0.15 | <0.05 | ~ |
| 6463 | 0.2~0.6 | 0.45~0.90 | <0.15 | <0.20 | <0.05 | <0.05 | ~ | ~ |
| 6005 | 0.6~0.9 | 0.40~0.60 | <0.35 | <0.10 | <0.10 | <0.10 | <0.10 | <0.10 |
| 6061 | 0.4~0.8 | 0.80~1.2 | <0.70 | 0.15~0.4 | <0.15 | <0.25 | 0.04~0.35 | <0.15 |
| 6082 | 0.7~1.3 | 0.60~1.2 | <0.50 | <0.1 | 0.4~1.0 | <0.20 | <0.25 | <0.10 |
| 6351 | 0.7~1.3 | 0.40~0.8 | <0.50 | <0.1 | 0.4~0.8 | <0.20 | ~ | <0.10 |
2) Mechanical property
| Alloy | Temper | Tensile strength | Yield strength | Elongation |
|
6063 |
T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
| T6 | ≥ 205Mpa | ≥ 180Mpa | ≥ 8% | |
| 6061 | T5 | ≥ 265Mpa | ≥ 245Mpa | ≥ 8% |
Detailed Product Description
| Product Name: | Aluminium Construction Profiles | Alloy: | 6063,6060,6463 |
|
Material : |
Aluminium Alloy |
Surface Treatment: |
Mill Finished, Anodizing, Electrophoresis, Powder Coating, Polishing, Wooden grain, Sand blasting |
| Deep Process : | Milling, Drilling ,Bending, Cutting | Temper: | T5,T6,T66 |
