Home > Products > Gabion Boxes > Galvanized Double Twisted Hexagonal Woven Steel Gabion Boxes With ASTM A975-97 Standard
Galvanized Double Twisted Hexagonal Woven Steel Gabion Boxes With ASTM A975-97 Standard
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Corrosion Hexagonal Wire Netting Machine CE Certification For Making Stone Cage 2x1x1m
-
PLC Control Gabion Mesh Production Line , Netting Hydraulic Packing Machine
-
Industrial Gabion Production Line Twist Mesh Size 80 X 100mm Width 4300mm
-
Customized Galvanized Galfan Gabion 3x1x1 Wire Mesh Cage For Roadway Protection
-
Hexagonal Wire Netting Machine For Gabion Mesh Of Various Widths And Mesh Sizes
-
Higher Efficiency 100X120mm Mash Size Galvanised Wire Hexagonal Netting Machine
Product Details
| Brand Name | Konson | Place of Origin | China | |
| Model Number | KS-GH |
Product Description
Certification:CE, ISO9001, SGS, ASTMA, EN, BS standard.
galfan gabion/galvanized gabion
1.Standard:ASTM A975-97
2.Galvanized at least 250g/m2
3.Zn-5% or10%Al alloy
4.Fast delivery.
?
galfan gabion/galvanized gabion
Gabions is made of double twisted hexagonal woven steel wire mesh, as per ASTM A975-97
Gabions are filled with stones at the project site to form flexible, permeable, monolithic structures such as retaining?walls, channel linings, and weirs for erosion control projects. The steel wire used in the manufacture of the gabion is heavily
Galfan (zinc-5% aluminum-mischmetal [Zn-5 Al-MM] alloy) coated soft temper steel. A PVC coating is then applied to?provide additional protection for use in polluted, contaminated or aggressive environments: in salt, fresh water, acid soil or?wherever the risk of corrosion is present. The PVC coating has a nominal thickness of 0.02 in. (0.50 mm).
The gabion is divided into cells by diaphragms positioned at approximately 3 ft (0.9 m) centers. To reinforce the structure, all mesh panel edges are selvedged with a wire having a greater diameter.
Hexagonal Wire Netting/ Hexagonal Wire Mesh/ Gabion Boxes/ Gabion Baskets/ Stone Cages/ Welded Wire Mesh.
Applications:
Control and guide of water or flood
Preventing of rock breaking
Rock fall protection
Water and soil protection
Bridge protection
Strengthening structure of soil
Protection engineering of seaside area
Port project
Keep off dust wall
?Why always choose KONSON??
+ The earliest manufacturer of Gabion boxes in China.
+ We have experience of export business for more than 15 years.
+ Strictly Implement and meet international standard ASTM ,BS,EN STANDARD and pass ISO & SGS quality certificate system.
+ Complete material testing system and QC system.
+ Experienced staffs, the fastest delivery time.
+ Best service (Any enquiry will be replied within 24 hours).
