High Precision Surface grinding , Optical Profile Grinding Parts with 80 - 90 HRC Hardness

Precision Optical projector Profile Grinding process Parts for terminal stamping die

Product name: Precision Optical Profile Grinding Parts

1. Material using : imported Tungsten Carbide SKD11,SKH9

2. Size ; According customer requirement

3. Hardness: 80-90 HRC

4. Surface Grinding Precision : 0.002MM

5. Angle Clearness<0.05

6. OEM service

7. MOQ:1 PC acceptable

Production Flow

Heating treatment, Surface grinding , PG profile grinding, Wire cutting EDM, EMD , CNC milling , Milling are the main product process.

Production Normal Information

Chenghui Precise Mould?professional expertise and advance equipment

Chenghui Precision Mould?have more than 60 professional and skilled technicians ;10 master of optical profile grinding ,CNC milling, mirror EDM, wire EDM who were more than five years experiences working in foreign-owned enterprise. These talents ensure our product satisfy customer requirement quickly and our process skills are be industry leadership in mould machining field such as EDM and PG optical profile grinding.

Japan Waida PGX-2500SP type optical projector profile grinder ensure processing precision 0.001mm.

Sodick and Seibu?wire-cutting EDM, Sodick oil cutting EDM machines,linear motor drive, with newly narrow-gap discharge circuit,?ensure ?accuracy??within 0.005mm, flatness,verticality,and linearity within 0.002mm.

Quality Guarantee

Using dimensional and optical inspection equimentment,?Chenghui Precision Mould ensures that the tolerance and dimensional integrity of each part remains uncompromised.

Chenghui Precision Mould?operate ISO 9001:2008 system,?committing to continuous process improvement eliminating variability and inconsistency within the manufacturing process.

CPK control key point and key size.
