Bird View Wide Angle 360 Degree Car Camera System For the Hyundai IX35

Brand Name	CLD		Place of Origin	China
Model Number	IX35

Delivery Time:5-30 days upon order quantity
Certification:CE and ROSH
Bird View Wide Angle 360 Degree Car Camera System For the Hyundai IX35
Quick Details:
Type: 360 Degree Car Visual Security Parking System
Voltage: DC 12V
Car make: for all brand cars, buses, trunks
Resolution: 520TVL
Effective pixel: 668*576
MOQ: 1 set
Place of origin: Guangdong China.

?
Description:
360 degree visible parking system called the Around View Monitor, it gives the driver an eye view of all view for the car. It does this by using four wide-angle cameras that can view more than 180 degrees - one each at the front and rear of the vehicle, and one on each side door mirror. The images are relayed to a screen that shows the view from above and on the left, and a front or rear view on the left. Selecting forward or reverse gears determines whether you get the front or rear views. Meanwhile, 4 cameras\' view displays from the monitor at the same time. The system lets the driver see every corner of the vehicle when parking, allowing much more precise - and hopefully bump-free -parking sensors on all four corners of the car help the driver be absolutely sure about the car\'s positioning.
?

o Image sensor: CMOS high-definition sensor PC1089

o Waterproof and weather-resistant housing for outdoor use

o Good night vision performance, small noise and no color aberration

o 180° wide viewing angle

o Picture elements: NTSC/PAL

o Effective pixels: 668*576

o Horizontal resolution: 520TVL

o Video output: 1.0Vp-p 75Ω

o Low illumination: 0.5 lux

o Gain control: automatic

o White balance: automatic

o Backlight compensation: automatic

o Working temperature: -30 to 70°C

o Storage temperature: -40 to 85°C

o Waterproof level: IP68

Applications:

This unit is good for all brand cars, a helpful tool for drivers to park cars.
Specifications:
Key Specifications/Special Features:

System: ? ? ? ? ? ? ? ? ? ? ?o Left/right rear-view mirror cameras specially design for Toyota Crown

o Capture the image of 4 different views with the use of 4 wide angle cameras (fish-eye angle) installed around the car, after image processing and stitching and synthesizes to a panoramic view image with 360° from top-down (bird view) surrounding the car, and the panoramic view timely transferred to the display screen of the control center

o Equipped with DVR to record image from 4 cHelameras

Clear 360° bird view panoramic display around automobiles Super wide horizontal viewing angle (180°) Auto image mosaic Video output to DVD or monitor, image show in screen with remote control can be:

o Front view + bird view

o Rear view + bird view

o Left/right side view + bird view

Video output: CVBS/NTSC Resolution of video output: 800x480 DVR memory: micro SD card up to 32GB or mobile hard disk via USB USB: USB2.0 for connection to mobile hard disk, for DVR recording, for software upgrading, and for view DVR recording On screen set up menu Working voltage: 8 to 30V DC Working current: <500mA at DC 12V Working temperature: -30 to 70°C Storage temperature: -40 to 85°C DVR features: o Your on-site witness, automatically record when ignition on o Shutdown time-lapse delay recording o Synchronous video replay and recording o Manually open/close recording quickly o Replay video at any time o Date/time shown on video o Loop recording
