Stainless Steel 304 Cyclone Water Filter Automatic Contral Centrifugal Sand Separator

Automatic Contral Centrifugal Sand Separator?
?
?
Description:
?
Working principle
?
Cyclone sand filter is designed and manufactured on the screening principle that solid particles in the fluid swirling and flowing in the sand filter. It is a new separation device which combines filtering device ,when the water flow is under certain pressure, it flows from the inlet tangentially enters the sand filter, and generates violent whirlpool, since the sand and water is different in density, under the comprehensive action of centrifugal force, centripetal force and fluid drag force ,the low density water rises and discharged from the water outlet, high density sand discharges from the sewage outlet at bottom of the device .individual particles joint floating along the water flow will be filtrated by the second stage filtering device, so as to realize the purpose of sand removal.
?
Applications:
?
Mainly applied to treating and control the water quality of the raw water and water supplying, such as: river water, well water desanding, coal washing water, mineral separation, solid-liquid separation, gas and liquid immiscible liquid separation.
?
?
Product features:
?
No energy consumption, good sand removing effect, especially suitable for sand content higher system using.
Low cost, convenient installation and operation, safe and reliable operation, small size, processing a large quantity of water, small occupied area.
?
?
FAQ:
?
01. What is the capacity (m3/hour)you required for this equipment?
02. What is the material for this cyclone filter?
Carbon steel ?or stainless steel (SS304/SS316)?
03. What is the power supply in your country?
220V/60Hz or other?
?
Specifications:?
