2 Way High Flow Concealed Thermostatic Shower Mixer Valve , Thermostatic Bath Taps

FOB Price

Negotiable / Square Meter

1 Square Meter(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	honch		Place of Origin	China
Model Number	HCTV002v

Product Description

Delivery Time:3-4 weeks

concealed ?Thermostatic Shower Valve 2 way high flow design?

Feature:

Thermostatic design, means no need to adjust temperature hardly each time,never worry about scalding or drop in temperature again.with 3 round handle and decorative plate,?1 for thermostatic control handle and 2 for outlet on/off control handle ,plate for cover the install hole .full brass made ,chrome finish ,high flow design ,especially suitable in low water pressure but still keep normal outlet flow rate .will supplies water to either a fixed shower head, a handset, body jets or tub filler.....

Specifications:

Weight?	5kg?per?piece?
Overall?Dimensions	(H?x?W) 330mmx180mm
Connection	3/4\'Inlets?and?Outlets?Compatible?with?standard?plumbing?connections
handle?	3 handle?
Cartridge size?	48mm?dia?cartridge?.
work?pressure	0.05Mpa-1Mpa,ideal?0.1-0.5Mpa,installation?reducing?valve?while?exceeding?ideal?pressure?.
Work?temperature	Pre-set?maximum?temperature?85C,ideal?hot?water?supply?temperature?60-70C?,cold?water? 5℃-29℃
?temperature adjust?	Thermostatic?cartridge?with?preset?temperature?stop?38°C?and Separate?controls?for?temperature?outlet?range?20-50C
Safe?device	Automatic?anti?scald,if?cold?water?supply?fail?,hot?flow?rate?will?be?reduced?to?virtually?shut?off
note	using more functions?simultaneously?may?reduce?the?water?flow?to?both?outlets.

Working requirement :

Suitable working for combine boilers ,gravity fed systems ,unvented mains pressure systems and for shower pumps.
?

Advantage :

1. Thermostatic control means no more fluctuations between cold and hot water 2. higher flow rates? design , can work at low or high water pressure but always keep normal outlet flow rate . 3. made?from?62#?brass,pressure?casting?process,high?density,It’s?Green,?Clean?and?Hygiene? Products 4. the? plates are adjustable by 35mm? for easier install ,suitable for DIY choose? 5. Leak Resistance: Passed the leak tests repeatedly to avoid the leak, even at high pressure up to 2Mpa 6. All components are replaceable without removing the valve ,easy maintenance 7. With non return valves ,never worry scalding or drop in temperature 8. Removable filters to trap debris 9. 1/4 turn on/off cartridge ,easy operation 10. from specialized thermostatic products manufactory ,full experience in thermostatic products more than 15 years 11. we offer full range of shower component ,can be combine to many shower set design 12. 3 year quality guarantee ?
