High resolution full color mobile Outdoor Advertising LED Display , Anti - frozen

Brand Name	ZCLED		Place of Origin	China
Model Number	ZCLED-O-F-P16

Delivery Time:15-25 days after receiving deposit
Certification:CE,ROHS, FCC,CCC

High resolution full color mobile Outdoor Advertising LED Display , Anti - frozen

Features:?

1.?High?brightness?DIP: 7500nits.

2.?Anti-UV?ray?mask.

3.?Weatherproof?design,?completely?outdoor?use.

4.?Easy?for?assembling?and?connection?with?the?connector?added.

5.?High?color?uniformity?and?clear?image?

6.?Both?front?and?rear?access?are?available.

7.?The?LED?Chips?: Taiwan Opto and Silan.

8.?same?level?of?red,?green?and?blue?led?chips, led?display?more?excellent?and?uniform.

9.?The?maintenance?of?pixel?and?single?led?has?been?realized.

10.?Good?quality?raw?material,?accurate?technique?and?careful?inspection?insures?the?high?quality?of?led?display.

11.The?shape?and?size?can?be?made?according?to?your?requirement.

Application and function:
?
Suit for advertisement, stage, stadium, exhibition, TV-Show, mansion video wall, shopping mall, banks, schools, bus station, airport, gym, market, factories, monitoring centers, hospitals, bars etc.
?
1. Video display for advertisement
2. Live broadcast for news, sport, concert…
3. Dynamic display for logo, text, video
4. Information display for time, schedule, text
5. Stage background
?
?
Function and Technology Character:?
?
1. Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
2. Information source can be camera, video, VCD, DVD, LD, TV and so on.
3. One interface for sound signal and two for video signal at least.
4. Multiform language editions, such as English, French, Germany, Greek, Russian and so on
5. Connected and controlled by PC via Lan and remote control.
6. Super correcting technology for distortion.
7. Clear picture without flicker and distortion.
8. Show everything with your PC does synchronously.
9. Brightness, contrast, saturation can be adjust by itself and manual.
?
?
Advantage of our factory:

Fully automatic machine production, can ensure the consistency of the LED, the tin point is uniform and full, can greatly avoid the cold solder, false solder, dead solder. So that to guarantee the color consistency and the stability of the display. Fully automatic machine production, also greatly reduce the cost of the labors, reduce our cost of production, so our price is much competitive. Constantly update and application of advanced technology. Full color display is our main product, fix install and rental business for advertising, concert, performance and so on. Synchronous and asynchronous system. Base on client’s requirement. New cabinet design,weight light and convenient.? We have new design 3G control system display, with GSM system, can be remote control, one can control more. If clients want.

Specifications?:

List	Item	Description
1	Pixel?Pitch	16mm
2	Module?Size	256*128mm
3	Pixel?Density	3904/sqm
4	Pixel?composition	1R1G1B
5	LED?Type	DIP346
6	Module?Resolution	16*8
7	Power?Consumption?of?Module	24W
8	The?Optimum?Viewing?Distance	16m
9	The?Optimum?Viewing?Angle	110°
10	Maximum?Power?Consumption	800W/sqm
11	Cabinet?Size	1024mm*1024mm
12	Cabinet?Resolution	64*64
13	Cabinet?Weight	50Kg ?Wate-proof
14	Driving?Method	Static Scan?Constant?Current?Driving
15	Frame?Frequency	≥60Hz/s
16	Refresh?Rate	≥360Hz/s
