Fruit Juice / Wine / Pure Drinking Water Bottle Filling Machine for PET Bottle

Brand Name	BJM		Place of Origin	China
Model Number	CGF32-32-6

Delivery Time:30 days after bottle sample received
Certification:ISO9001, CE

Fruit Juice / Wine / Pure Drinking Water Filling Machine for PET Bottle 3L to 4 Gallon

Quick Detail:

Capacity: 5,000?bottles per hour (5L) We?supply 400 to 5,000?bottles/hour Bottle Type:3L to 20L Washing Head: 30?PCS Filling Head: 30?PCS Capping Head: 6?PCS Machine Type: Rotary?Filling Machine Warranty: 1 year and free spare parts in one year Engineers available to service machinery overseas Full line including: Bottle Feeder,?Rinser-Filler-Capper 3 in 1 machine Rotary/Linear, Lamp Checker, Labeling Machine, Film Shrink Machine/Carton Packing Machine Application:?Pure water/Mineral water/Drinking water/Non-carbonated water/Beverage/Codiment etc Cap Type: Screw cap, Pressing Cap, Sport cap Bottle Type: PET/PP/PE/HDPE Plastic Bottle Place of Origin: Zhangjiagang city, China near Shanghai Brand: BJM Bottle Shape: Round/Square/Rectangular/Irregular Delivery Time: 30 days Shipping: Sea

Specifications:

Application	Pure water/Mineral water/Drinking water/Non-carbonated water/Beverage/Codiment etc
Suitable bottle Type	3L to 20L
Suitable cap type	Plastic Screw Cap/Pressing Cap/Sport Cap
Supply Capacity	2,000 bottles per hour(5L?bottle)
Filling Type	Mico Low Negative filling type
Filling Temperature	Ambient/Room Temperature
Voltage	220/380V(Custom made)
Power	50HZ/60HZ(Custom made)
Automatic Grade	Fully Automatic
Driven Type	Electric
Material:	High quality SUS304 stainless steel
After-sales Service?	Engineers available to service machinery overseas

Description and feature:

Automatic Rinsing

Fixed structure, impeccable controlling system and easily for operating and maintain. Professional cleaning machine for empty plastic bottle. Reliable cleaning theory and spraying method to rinse the inside and outside of the bottles. When change the bottles, only need to adjust some spare parts, no other machine accessory need to change; this machine is suitable for rinsing PET bottles,?can be used for big-size and further develop enterprise, not only for the whole filling line, but also for the separate working;

Automatic Filling

The machine can fill the PET bottle which can to be 20L. Filling valve uses German advanced technology, even with running speed 5,000 bottles per hour, our machine can fill stably and exactly; All filling accessory have been well polished, and have nice appearance , fast filling speed, without any leakage; Themachine is equipped with anti-reverse rotation unidirectional clutch device. When it overload, the clutch will slip to stop the machine, so that the machine can work normally.

Automatic Capping

The?capping machine is suitable for plastic screw cap , aluminum screw cap,pressing grand cap, etc which is mainly used in the PET bottled no-gas drinking ; The capping machine has the stable transmission system, great sealing performance, easy operation, convenient maintance character. Main?motor ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?? ??? ?Siemens Liquid?level?sensor ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? France Pump ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?South Pump(China Famous Brand) Touch?screen ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?? ?Taiwan PLC ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? Mitsubishi? Inverter ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?? Mitsubishi Photoelectric?switch ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? Omron Contactor, Circuit?breaker ? ? ? ? ? ? ? ? ? ? Snyder France Bearing ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?NSK?Japan Seal?ring ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ???U.S Material?contact?valve,?tank,?pipe ? ? ? ? ?SUS304/316L

All Parts we can custom made for requirement for each customer, like Grundfos Pumps, Sew Motor, Festo Electric Appliance, etc.

Competitive Advantage:

Experienced in this field more than 20 years Free technical support&consultation Professional & fast after service team Warranty: 12 months Free spare parts for one year Delivery time: in time Engineers available to service machinery overseas

When you send inquiry, please also included the capacity and bottle volume you need to work on the machine, it is eas
