Beverage / Mineral Water Monoblock Automatic Liquid Bottle Filling Machine 50HZ / 60HZ

Brand Name	BJM		Place of Origin	China
Model Number	CGF32-32-12

Delivery Time:30 days after deposit and bottle sample received
Certification:ISO9001, CE

500ml/750ml/1.5L 12,000BPH Industrial Automatic Water Bottle Filling Machine/Rinsing Filling Capping Machine?

Quick Detail:

Model: CGF32-32-12?3 in 1 Monoblock Place of Origin: Zhangjiagang city, China near Shanghai Brand: BJM Application:?Pure water/Mineral water/Drinking water/Non-carbonated water/Beverage/Codiment etc Capacity: 10,000 to 12,000 bottles per hour Rinser Head: 32pcs Filler?Head: 32pcs Capper?Head: 10pcs Bottle Type: 200ml to 1.5L/2L to 10L Cap Type: Screw cap, Pressing Cap, Sport cap Bottle Type: PET/PP/PE/HDPE Plastic Bottle Bottle Shape: Round/Square/Rectangular/Irregular Full line including: Bottle Sorter,?Rinser-Filler-Capper 3 in 1 machine, Lamp Checker, Labeling Machine, Film Shrink Machine/Carton Packing Machine

Specifications:

Application	Pure water/Mineral water/Drinking water/Non-carbonated water/Beverage/Codiment etc
Suitable bottle Type	PET bottle with size 200ml to 1500ml/2L to 10L
Bottle Height	Bottle height. Φ160—φ340mm
Bottle Diameter	Bottle dia.φ50-φ90mm
Suitable cap type	Plastic Screw Cap/Pressing Cap/Sport Cap
Supply Capacity	10,000 to 12,000 bottles per hour(500ml bottle)
Filling Type	Mico Low Negative filling type
Filling Temperature	ambient/Room Temperature
Voltage	220/380V(Custom made)
Power	50HZ/60HZ(Custom made)
Automatic Grade	Fully Automatic
Driven Type	Electric
Material:	High quality SUS304 stainless steel
After-sales Service?	Engineers available to service machinery overseas

Description:

1,?The water filling equipment?is used in filling mineral water, purified water, still water etc in bottles made of polyester and plastics. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles.

2, The rinser,?filler?and?capper?3 in 1 job can?be?finished?by??one?machine?automatically, the bottle goes through rinsing, filling and capping with little abrasion, and the transferring is stable, and bottle changing is easier.

3, The machine operation is faster and more stable because the micro gravity filling operation of the new type is adopted. There the output and benefit of the machine is higher than the machinery of the same specifications.

4, ?The full line water filling equipment? includes: Washing-filling-capping 3 in 1 machine, lamp checker, label shrinking machine, code?printer, hot shrink packing machine/carton packing machine and conveyors. It is a full automatic production line.

5, Spares contact with the liquid are all of excellent stainless steel or food level plastic. The electric system is of international brand and achieves the national food sanitary standard.

Main?motor ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?? ??? ?Siemens Liquid?level?sensor ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? France Pump ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?South Pump(China Famous Brand) Touch?screen ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?? ?Taiwan PLC ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? Mitsubishi? Inverter ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?? Mitsubishi Photoelectric?switch ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? Omron Contactor, Circuit?breaker ? ? ? ? ? ? ? ? ? ? Snyder France Bearing ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?NSK?Japan Seal?ring ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ???U.S Material?contact?valve,?tank,?pipe ? ? ? ? ?SUS304/316L

All Parts we can custom made for requirement for each customer, like Grundfos Pumps, Sew Motor, Festo Electric Appliance, etc.

Competitive Advantage:

1, Water Filling Machine uses neck handling by grippers bottle transmission, 2, Fully automatic rinsing, filling and capping by PLC control; 3, No bottle no rinsing; 4, International brand Electrical components; 5, All material?contact parts are made of qualified stainless steel, wearable, stable with less malfunction; 6, Using starwheel as its drive mechanism, which realize automatically rinsing, filling and capping.
