Cold Steel Pharmaceutical Cleanroom Air Shower 99.995% Efficiency , 1400 2000 2100mm

Cold Steel Pharmaceutical Cleanroom Air Shower 99.995% Efficiency, 1400 × 2000 × 2100mm

Quick Details:

1. Name: YJ-S-1CS Outside Cold Steel Air Shower

2. Brand Name: Yijing

3. Material: Outside Cold Steel, Inner Side Stainless SteelSUS304

4. Feature: Automatic Control

5. Outside dimension: 1400×1000×2100(mm)

Description:

Applicable Number of People:1 person

Materials: Outside Cold Steel, Inner Side SUS304

Number of Nozzle:12(Two Sides) Stainless Steel 304

Mouth Diameter of Nozzle: Φ30mm

Speed of Air Flow at the Nozzle: >25m/s

Dimension of High Efficiency Air Filter (mm): 600×600×120

Dimension of Air Shower Area (mm): 800×900×1960

Outside Dimension (mm): 1400×1000×2100

Lock: Electronic Interlock

Pre-Filter: 600*350*10(mm), 2PCs, synthetic fiber with aluminum

HEPA Filter: 2PCs, 600*600*120(mm)

FAN: 2PCs, Power: 0.55KW, Air Volume: 1500/PC, Air?Pressure:1200Pa

LAMP:1PCs, Power: 20W

Shower Time: 0-99s adjustable

HEPA Filter Efficiency: H13, 99.995%@0.38um

Maximum Power Consumption: 1.1 KW

Specifications

How to use Air Shower?

First, the user enter into the work area, open the door, while the door is auto closed after enter in to the air shower, Auto Showering start, then power off after shower, then the user exit the door enter to clean area. Lastly, the door is auto closed.

Applications:?

1. As the filtration equipment through the action of high strength air flow, the single person air shower room is often used in conjunction with clean room. It can remove the impurity such as dust on the working staff before they go into the clean room. Each side of our product has six nozzles with a wide distribution range. With the mouth diameter of 30mm, the nozzle can spray out the air quickly and the air shower area can be up to 800×900×1960mm. The air shower time can be adjusted in the range of 0 to 99s. Thus, the air shower effect can be assured to be the best level, which guarantees the cleanliness of the clean room completely.
?

2.The single person air shower room is assembled with foam insulation color siding and aluminum component. It is equipped with centrifugal fan and the primary and high efficiency air filters. The product has the features of elegant appearance, compact structure, easy maintenance and simple operation. Meanwhile, we can produce the peo
