Home > Products > MAG Welding Machine > Automatic Tube To Tube Sheet MIG / MAG Welding Machine For Boiler Industry
Automatic Tube To Tube Sheet MIG / MAG Welding Machine For Boiler Industry
Negotiable
/ Piece
1 Piece(Min.Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Dual Purpose SAW / MAG Welding Machine 640mm/min , Width 4500mm
-
Two Work Position Membrane Panel MAG Welding Machine For Industrial Boiler
-
20 Torches Subunit Panel MAG Welding Machine For Heavy Power Plant
-
Tube To Tube Sheet Automated MAG Welding Machine Horizontal / Vertical Position
-
Dual Purpose SAW / MAG Membrane Panel Welding Machine For Boilers
-
Industrial Boiler Membrane Panel MAG Welding Machine 640mm/min
Product Details
| Brand Name | WTEC | Place of Origin | China | |
Product Description
Automatic Tube To Tube Sheet MIG / MAG Welding Machine For Boiler Industry
Description:
All position welding is adopted, automatic welding with high efficiency.
Welding torch with weaving function, weaving parameter can be easily adjusted.
Welding torch realize automatic alignment through positioning tooling, which compensates negative influence by slanted tube.
Applications:
It is mainly used for convection tube bundle or tube to tube sheet welding for boiler industry, to realize all position automatic MAG welding.
Specifications:
| Wire feeding speed | 3～7.5m/min |
| Rotating speed | 0.6～2.3r/min |
| Weaving frequency | 0～145 times/minute(adjustable) |
| Weaving range | 0～10 mm |
| Wire diameter | 0.8mm |
| Mixed gas ratio | 80％Ar＋20％CO2 |
| Compressed air | 0.5MPa |
Contact Us
- Wise Welding Technology & Engineering Co., Ltd.
- Contact nameMs. Catherine Chat Now
- Phone86-10-60262121
- AddressWelding&Industrial Zone, No.6, Jinger Road, Ningbo, Zhejiang
