Home > Products > Drilling Stabilizer > 4145Mod / 40CrMnMo EAF Replaceable Sleeve Drilling Stabilizer For Wear-resisting Belt
4145Mod / 40CrMnMo EAF Replaceable Sleeve Drilling Stabilizer For Wear-resisting Belt
- T/T L/C D/P D/A
- 7 days
You May Like
-
Mn 1.05 - 1.20 Mo 0.25 - 0.35 190mm 40CrMnMo Replaceable Sleeve Drill Stabilizer
-
Custom 1800 - 1900 mm 0.20 - 0.35 40CrMnMo Replaceable Sleeve Stabilizer Drilling
-
ASTM A388 UT 40CrMnMo Three Roller Drilling Stabilizer For Heavy Weight Drill Pipe
-
High Presicion 4145H / 4145Mod / 40CrMnMo Three Roller Drilling Stabilizer ASTM A388
-
200 L2 40CrMnMo Three Roller Driliing Stabilizer For Heavy Weight Drill Pipe
-
4145H / 4145Mod Three Roller Drilling Stabilizer For Heavy Weight Drill Pipe ISO
Product Details
| Brand Name | kyforging | Place of Origin | China | |
| Model Number | Stabilizer blade |
Product Description
Certification:ISO
4145HMod, 40CrMnMo EAF Replaceable Sleeve Drilling Stabilizer For Wear-resisting Belt
Description:
Replaceable sleeve stabilizer is made up of a body and a centralizer body, and its advantage is quickly replace centralizer body when the front is wear and failure. It is flexible and especially suitable to play directional well.
Applications:
Replaceable sleeve stabilizer is the important toolof oil, gas and geology exploration drilling engineering, prevent well deflection. It is mainly used in setting with arger in rigid drill collars and drilling pressure to make well deflection rate and orientation rate smaller, improving well deep quality and drilling speed, reducing the drilling cost.
Specifications:
1. Material: 4145H, 4145HMod, 40CrMnMo etc.
2. UT: ASTM A388
3. Smelting method: EAF+LF+VD
4. Heat treatment: normalizing + tempering + Q&T
5. Chemical component(%):
|
?C |
Si |
Mn |
?P |
S |
|
0.43~0.49 |
0.20~0.35 |
1.05~1.20 |
≤0.025 |
≤0.025 |
|
?Cr |
Ni |
?Mo |
Cu |
|
|
1.05~1.25 |
≤0. 25 |
0.25~0.35 |
. 20 |
6.Standard Stabilizer Sizes:
|
Hole size |
Body OD |
Fishing Neck length |
Blade Length |
Blade Width |
Tong Space |
Bore |
Oal Length |
|
8 |
4 3/4 |
30 |
15 |
3 |
25 |
2 1/4 |
72 |
|
8 1/2 |
6 1/2 |
30 |
18 |
3 |
27 |
2 13/16 |
78 |
|
12 1/4 |
8 |
30 |
18 |
3 1/2 |
28 |
2 13/16 |
83 |
|
12 1/4 |
9 1/2 |
30 |
18 |
3 1/2 |
28 |
3 |
83 |
|
14 3/4 |
8 |
30 |
18 |
3 1/2 |
30 |
2 13/16 |
90 |
|
14 3/4 |
9 1/2 |
30 |
18 |
3 1/2 |
30 |
3 |
90 |
|
16 |
9 1/2 |
30 |
18 |
3 1/2 |
30 |
3 |
92 |
|
17 1/2 |
8 |
30 |
20 |
3 1/2 |
30 |
2 13/16 |
94 |
|
17 1/2 |
9 1/2 |
30 |
20 |
3 1/2 |
30 |
3 |
94 |
|
20-26 |
9 1/2-11 |
30 |
22 |
4 |
30 |
3 |
110 |
|
Stabilizer size is designed according to customers’ requirements. |
|||||||
|
Wear-resisting belt types are HF1000, HF2000, HF3000, HF4000. |
Technical data?of Replaceable sleeve sta
