Horizontal Self-aligned Vessel Tank Rotator Welding Machine To Weld In Blue
Negotiable
1 (Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Custom Ajustable Convenient Tank Rotator , Self-aligned Welding Turning Rolls
-
1200 Ton Conventional Welding Tank Rotator For Construction Of Wind Tower
-
Fit-up Horizontal Tank Turning Rolls , Self-aligning Pipe Welding Rotators
-
Honda Copy WH168F Popular Compaction Plate Of Portable Type With Wheel Assembly
-
Concrete Vibratory Plate Compactor With Competive Price Compaction Plate
-
Honda GX160 Foldable Handle Compaction Plate With 4-stroke Engine
Product Details
| Brand Name | Yijie | Place of Origin | China | |
| Model Number | SAR |
Product Description
Certification:CE
Horizontal Self-aligned Vessel Tank Rotator Welding Machine To Weld In Blue
it Up Rolls, FUR SERIES: Designed for align and assembling shell to shell or section to section, round and conical. Ideal for construction of wind towers, steel vessels and tank
Standard package includes: a) One power rotator Model FUR WR with control box and 12.00 meters length remote control for adjusting of rotating speed, stop, forward, and reverse. Digital speed indicator set for mm/min is included, b) Three idler rotator Model FUR IR, c) Operation manual, d) One year guaranty.
Optional: a) Foot control pedal for control forward, stop and reverse rotation; b) Extra idler rotators Model FUR IR-IB may be required depending of work piece length; c) Rail tracks
?
Standard package includes: a) One power rotator Model FUR WR with control box and 12.00 meters length remote control for adjusting of rotating speed, stop, forward, and reverse. Digital speed indicator set for mm/min is included, b) Three idler rotator Model FUR IR, c) Operation manual, d) One year guaranty.
Optional: a) Foot control pedal for control forward, stop and reverse rotation; b) Extra idler rotators Model FUR IR-IB may be required depending of work piece length; c) Rail tracks
?
Notes:
a) Custom built fit up rolls available. Required information: i) Tank weight, ii) Vessel diameter range (min- max)
b) Vertical adjustment of work piece: Both wheels of the same rotator has hydraulic?? lifting device which allows the wheels to move synchronized (right/left or left/right). While the wheel moves horizontally the work piece is lifted/lowered vertically
c) Horizontal adjustment of work piece: Two rotators have a hydraulic device which allows each wheel to move independently (right/left or left/right) for? horizontal adjustment
d) Fit up detailed sequence: Available under customer request
e) Inside and outside circumferential seam welding: By means of a Welding Manipulator WM Series with SAW head
Product Application:
Used to weld, polish and assemble the cylinder-shells, and to line the shells with rubber.
Product Advantage:
Fit-up type, convenient
high quality
Reasonable price
good service
?
Competitive Advantage:
1. All the bolt using 12.9 grade Bolt , not using 8.4 grade. Making the machine more stronger.
2. 20 % overweight design , could making the rotator focus more.
3. Double row wheels ,not only making the wheels stable, but also artifacts to increase friction.
4. All the parts using well-known brands in China or other countries . Quality is more reliable .
5. Using double row bearings.
6. The base of rotator welded by plates, with high strength, no deformation after long time using.
